Wholesale Cheape Flexible Pvc Pipe Size

Wholesale Cheape Flexible Pvc Pipe Size thumbnail-1
Wholesale Cheape Flexible Pvc Pipe Size thumbnail-2
Wholesale Cheape Flexible Pvc Pipe Size thumbnail-3
Wholesale Cheape Flexible Pvc Pipe Size thumbnail-4
Wholesale Cheape Flexible Pvc Pipe Size thumbnail-5
Wholesale Cheape Flexible Pvc Pipe Size thumbnail-6
Wholesale Cheape Flexible Pvc Pipe Size photo-1
Wholesale Cheape Flexible Pvc Pipe Size photo-2
Wholesale Cheape Flexible Pvc Pipe Size photo-3
Wholesale Cheape Flexible Pvc Pipe Size photo-4
Wholesale Cheape Flexible Pvc Pipe Size photo-5
Wholesale Cheape Flexible Pvc Pipe Size photo-6
US$ 1.00 - 2.00 MOQ: 100 Meters
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
GM pvc pipe size
Model Number:
pvc pipe size
Contact Supplier Request Quote Chat Now
Luoyang Gaoming Plastics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name GM pvc pipe size
Model Number pvc pipe size
Material PVC
Specification 7.0-54.5
Length Roll
Thickness 2mm
Standard ISO9001
PVC corrupgated pipe

Product Description

PVC corrugated pipes have two categories: The single Walled Corrugated pipe (SWC and Double Walled Corrugated (DWC). the main raw material of PVC corrugated pipe is PVC, This is a Flexible

Sink Drain Hose ,this kind pipe owned both rigid and soft features. The Inner and outer surfaces

are corrugated, bending, flexibility. The single wall corrugated pipes, thin-walled, little requirements

of strength, it can bend freely and have small diameter tube.

Product property
Size
50-200mm
Material
Polyethylene, flame retardant
Working Temperature
-30°C-+100°C, short time to +120°C
Color
Black, other colors can be customized

Features
Good flexibility twist, resistance, bending
resistance, abrasion acid, oil, coolant,etc.
 Shiny surface can withstand heavy loads.


Carrying Capacity
Can withstand the weight of foot,
no broken, deformed, can be quickly
restored and without any damage itself.

Application Area
Applicable to machine tools, power
equipment, food machinery, automotive
instrument, motor industry etc.
Package
With poly bags or cartons bags or cartons
pvc corrupgated pipe

Application area

◆ Transport certain liquids and gases.
◆ Embedded wire casing.
◆ Widely used for drainage, flooding at golf                   courses, sports fields and other light load                   conditions.

◆ Interior decoration wire casing; automotive               wire casing; pre-stressed anchor sleeve; air               conditioners drainage pipes.

Specifications of PVC SWC corrugated pipe

Part Number
Specifications
ID x OD(mm)
Curved radius(mm)
Packaging unit(mm)
PVC-7.0
AD-7.0
4.5x7.0
10
200
PVC-10.0
AD10.0
6.5x10.0
15
100
PVC-13.0
AD13.0
10.0x13.0
25
100
PVC-14.0
AD14.0
11.0x14.0
25
100
PVC-15.8
AD15.8
12.0x15.8
28
100
PVC-18.5
AD18.5
14.3x18.5
35
100
PVC--20.0
AD20.0
16.0x20.0
38
100
PVC-21.2
AD21.2
17.0x21.2
40
100
PVC-25.0
AD25.0
20.0x25.0
42
100
PVC--28.5
AD28.5
23.0x28.5
45
100
PVC-32.0
AD32.0
25.0x32.0
50
50
PVC-34.5
AD34.5
29.0x34.5
55
50
PVC-42.5
AD42.5
36.0x42.5
65
25
PVC-54.5
AD54.5
48.0x54.5
80
25

Product character

◆ Utilizing its annular groove can be both

    rigid  and flexible.
◆ Mostly thin walls, used in area that not

    high requirements of strength.
◆ Freedom bent pipes of small diameter,

    such as threading pipe, drain water pipe,

    the exhaust pipe.

Packing & Delivery

with poly bags or cartons bags or cartons

Our service
Certification

Our company strictly follows the ISO9001 quality assurance system. These compounds are accurately processed under the firm guidance of our highly qualified experts using quality tested chemical in order to meet the industry preset standards.These compounds are properly checked on purity and moisture resistance parameters by our quality inspectors prior to the final delivery.

Our service

After Sales service: In order to provide the first-class service. We are committed to continue to track the sale of pvc compound, and solve the problems caused by the product quality we have.
Free Sample service:We provide free samples from 1 to 3kg accordingly. The express fee need to be prepaid by the customer before delivering.

logistics information

                                          ●UPS, FedEx, and DHL Express is available.

                                          ●Shipped within 2 weeks after receipt of your order

                                          ●Delivery around 5-7days after receipt of deposit payment.


Company Introduction

Company Introduction

Luoyang Gaoming New Materials Co., Ltd. was established  in  1998  and  got  its current name in 2009. Since its initiation, we have always followed the principles of product-oriented , quality-based and technological R&D-focused.

We  are  reputed  manufacturer,  supplier  and importer of a broaden of a broad assortment of Raw Material and Plastic product.PVC/PPR pipe Recycled plastic,HV/MV/LV cable compound,PVC cable compound, plastic sheet are offered by us.


Our professionals incorporate automatic and semi-automatic modern machinery to produce these products in bulk quantities.

After almost two decades of development, our company  has  become  a  modernized  large-

scale business that focuses on macromolecular compound  R&D  and  production  with  3 branchfactories.

What We Offer?

We are engaged in manufacturing a wide range of plastic materials:
☞PVC/PPR pipe
☞Recycled plastic
☞HV/MV/LV Cable Compound
☞PVC Cable Compound
☞Plastic Sheet
