Mini 1.0MP HD 3.6mm Fixed Lens 720P Security IP Camera P2P Onvif

Image Sensor

Sensor

1/4’’ CMOS sensor, 1 mp/1.3mp for optional

Lens

f: 3.6mm F: 2.0

Minimum illumination

0.5Lux

visual range

90 degree

Video

Video compression

H.264

Working frequency

50Hz, 60Hz

Image frame rate

25fps (50Hz/60Hz), auto downward adjustments

Image resolution

1280*720, 640*480(VGA); 1280*960 for optional

Video bitrate

128-8192K (adjustable)

Image adjustment

Brightness, contrast, saturation and hue can be adjusted

Network

Infrared mode

Automatic / manual

Night vision

10*F5 infrared lights, infrared irradiation distance: 8meters

Supported protocol

HTTP,FTP,TCP/IP,UDP,SMTP,DHCP,PPPoE,P2P,UPnP,GPRS

Wireless standard

WIFI(IEEE802.11b/g/n)

P2P

Point-to-point Connection , No Need to do Port forwarding, Easy to USE

Access protocol

Support ONVIF 2.0

Alarm

Alarm detection

Motion detection

Alarm notification

Support Email, FTP alarm notification

Hardware interface

Power interface

DC 12V/2.0A (EU/English/American Plug)

Input

Built-in MIC, can achieve two-way audio

Output

Built-in speaker, can support external earphone

Reset button

1 reset button

Network interfaces

Wifi 802.11b/g/n

TF Card

Support Max 32GB

Environment

Operating temperature

0° ~ 55°C  (32°F ~ 131°F)

Operating humidity

10% ~ 80% (non-condensing)

Storage temperature

-10°C ~ 70° (14°F ~ 140°F)

Storage Humidity

0% ~ 90%(non-condensing)

PC Requirements

CPU

2.0GHz or above ( suggested 3.0GHz )

Memory size

256MB or above (suggested 1.0GB)

Graphics card

64MB or above

OS

Microsoft Windows 2000/XP, Vista, Windows7, Mac OS, Linux

Browser

IE6/IE7/IE8/IE9,Firefox,Safari,Goolge Chrome,other standard browsers

Certification

Certification

CE, FCC, ROHS, EMC10M
