2015 New liquid agitator
- 500 Set / Sets per Month
- Guangdong China (Mainland)
- T/T L/C Credit Card PayPal
Product Details
Condition: | New | Mixer Type: | Agitator | Product Type: | Cosmetic |
Application: | Viscous Fluid | Additional Capabilities: | Milling | Place of Origin: | Guangdong, China |
Brand Name: | JCT | Model Number: | QF | Max. Loading Capacity: | 4000L |
Voltage: | 380~450V/3 Phase/ 50Hz | Power(W): | 0.75KW-55KW | Dimension(L*W*H): | 1.5m*1m*2m~4m*2m*5m |
Certification: | ISO9001,ISO14001,CE | Warranty: | 18 months |
Packaging Details
Standard Export Cases, Standard Neutral packing, wooden package
Product Description
Specifications
liquid agitator
1.Frequency control
2.Technology supply
3.Blending & Shearing
4.ISO9001, CE
1. Instruction of the Strong disperser:
1) The lab disperser is a good choices, which designed for mixing, vulcanization,
nitration, sulfonation, hydrogenation, dehydration in viscous fluid.
2) The lab disperser has 3 motors & 1 reducer. 2 high speed motor to cut the material.
The motor in center has reducer to output a big moment of force,its rotate E type blades
is designed for scraping the wall and the bottom.
3) The lab disperser has special seal structure to keep inside low up to -0.096Mpa.
4) There is a double layer jacket type movable vessels.The heat transfer media can
be chosen by thermal oil, water or steam.
5) The material mixing in the movable vessel, when it finished push it out.
6) The discharging mode are:YLJ series hydraulic discharging machine or ball valve.
7) There are variety of equipments can be installed such as: stroke control,
safety control, measurement, temperature Pt-Rh sensor, etc.
8) In default the steel is SUS304+Q235.The motor capacity will be selected according
to the viscosity of the material.
9) Other issues will be designed according to the best solution.
2.Strong Disperser applies for:
1) Silicone sealant
2) paint
3) cosmetics
4) Others: other viscosity liquid and paste material
disperser
liquid agitator
3. The parameter of theStrong disperser:
Specifications and Models | volume ( L) | Motor Power (KW) | Revolving Speed (rpm) | Vacuum Degree (PMa) |
Remarks | ||
Mixing | Dispersion | Mixing | Dispersion |
|
| ||
QF-5 | 5 | 1.1 | 1.1 |
~20 |
0-1000 |
-0.095 | Laboratory Equipment |
QF-350 | 350 | 5.5 | 15*2 |
| |||
QF-600 | 600 | 11 | 22*2 | ||||
QF-1100 | 1100 | 22 | 30*2 | ||||
1. Lifting Way: Hydraulic lifting 2. It can be heated and cooled as needed 3. Pressure range: -0.098MPa 4. Speed control method: Variable frequency speed regulating |
liquid agitator
4. Pictures of the Strong disperser
Large-scale Lab Disperser & Hydraulic discharge machine
Medium-scale Lab Disperser& Hydraulic discharge machine
Small-scale Lab Disperser& Hydraulic discharge machine
Blade of Strong Disperser
liquid agitator
5.Packaging & Shipping Lab disperser
Lab disperser
1. Wooden case packing if necessery.
2. Very big machines packed by plastic bags OR nude package.
3. We can supply shipper, or buyer can assign the shippers.
Lab disperser
