SL-LL-A2 type faucets seal flowsensitivity test rig
[Testing items]
[Applicable standards]
Mainly based onGB18145-2014 Ceramic cartridge faucets, GB / T23447-2009; EN1112-2008;EN1113-2008 such as faucets and shower products for sealing flow andsingle-handle faucets agility class dual control performance test.
[Features]
The bench has areasonably simple operation, high measurement accuracy, LED interface, easyoperation, visual display, the test results can be saved reports can be printedand so on. Industrial control and programmable controllers make the experimentcontrol more accurate and reasonable. Using multiple pump-stainless steel benchcan run in different conditions, to meet the different requirements of theexperiment, easy to operate. Thermostatic faucets control mechanism allows formore precise stepper motor. System mainly flow components are made of copperand stainless steel piping, make the system more clean and durable. Using thesystem for pressure regulator device is very stable, comes with water features,a leading level of faucets bathroom products testing station.
[Technical parameters]
Pressure test range: static0.05-3.5MPa
0.05 ~ 0.5MPa ± 0.01Mpa
Pressure sensors: Accuracy: 0.5%
flow sensor: Accuracy: 0.5%
Stepper motor speed adjustment: 0.5 °/ s
Flow Test Range: 0.08 ~ 2.8m3 / h Accuracy :1
Temperature range: room temperature——80 ℃,cold water: -10 ℃—roomtemperature
The number of specimens synchronous detection: 1 to 2 (testedseparately)
Equipment Supply: ~ 380V 13kW
weight: 1000KG
length × width × height (mm): Console: 1200 × 1100 × 1910
Station: 1200 × 1100 × 1910
Refrigeration units: 800 × 400 × 600
Package and shipment
CERTIFICATION
OUR CIVIL AND INTERNATIONAL CUSTOMERS :
Cooperated with China Academy of Launch Vehicle Technology (CALT):
