Glow Wire 960 degree flameless PolyCarbonate plastic raw material manufacturer

FOB Price

USD $3.6 - $8.3 / Kilogram

25 Kilograms(Min.Order)

Supply Ability 10 Ton / Tons per Month
Port Huangpu port/ Nansha port
Payment TermsT/T L/C D/P D/A Credit Card

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Place of Origin	Guangdong, China		Brand Name	GYD
Model Number	PC-T110F-GWF960

Product Description

GWIT Basic introduct

1.The device is designed to carry out fire hazard testing on electrotechnical products in accordance with the provisions of International standards.

2.The control unit is supplied with all the controls and metering necessary to accurately set the temperature of the glow wire. The wire current is continuously variable by means of the panel-mounted controller and is monitored by the built-in ammeter.

3.A digital temperature indicator is fitted which, in conjunction with the thermocouple supplied, accurately measures the glow wire temperature. The electrical circuit of the control unit is fully protected by fuses and a miniature circuit breaker and incorporates mains on/off switching and push button control of the output current. Self contained cabinet with large viewing window and dark colored interior.

GWIT Technical

::::::::::::Technical parameters::::::::::::

1, Glow wire temperature: 500 ~ 1000 °C± 2 °C continuous adjustable

2, Searing time: 0-999.9 s ± 0.1 s adjustable (usually selected for 30s)

3 Light-off time: 0-999.9 s ± 0.1 s, automatic recording, manual timeout

4, Fireouttime: 0-999.9 s ± 0.1 s, automatic recording, manual timeout

5.Glow Wire Element Ni/Cr wire, diameter: 4mm

6.Current Range: 0 to 200 A

7.Thermocouple: Type K (Ni/Cr - Ni/Al)

8.Thermocouple Size O/D: 0.5 mm

9.Temperature Resolution: 1C

10.Traverse Unit: Horizontal

11.Force: 1 N±0.2N

12.Maximum Travel : 14.5 cms

Product Description

Glow Wire 960 degree flameless PolyCarbonate plastic raw material manufacturer

Application: mainly used in lighting lamps & lanterns, high & low voltage appratus, electrotechnical instruments and other eletric and electronic products & components, etc.

International certification: IS0-9001, UL, ROHS, REACH

PC-B110F-GWF960 property parameter table (Glow wire ignitability 960°C)
Property item		Test condition	Test method	PC-B110F-GWF960	Unit
Physical properties	Specific gravity		ASTM D792	1.2
	Water absorption rate		ASTM D570	0.15	%
	Melt index		ASTM D1238	15	g/10min
	Mould contraction rate	23°C	ASTM D955	5-8	E-3
Mechanical properties	Tensile strength (yield point)		ASTM D638	60	Mpa
	Tensile strength (rupture point)		ASTM D638	88	%
	Flexural strength		ASTM D790	80	Mpa
	Flexural modulus		ASTM D790	2100	Mpa
	Rockwell hardness		ASTM D785	118	R
	Impact strength (notched)	23°C	ASTM D256	640	J/m
Thermal properties	Heat deflection temperature	0.45Mpa	ASTM D648	139	°C
	Heat deflection temperature	1.8Mpa	ASTM D648	130	°C
	Vicat softening point		ASTM D1525	150	°C
	UL long-term using temperature with impact		UL746B	120	°C
	Glow wire ignitability		ASTM D2863	960	°C
	Flame retardant		UL94	V0
Electrical properties	Permittivity	1MHz	ASTM D150	2.95
Electrical properties	volume resistivity	1MHz	ASTM D257	1.00E+17	Ω-cm
