glow wire ignitability pc abs resin, Modified PC/ABS alloy plastic manufacturers
Advantages:
1. UL certification
2. ROHS SGS EU REACH environmental approval
3. Pencil hardness 6H (A S T M D 3 3 6 3)
4. Combustible Index 850 °C: 30 seconds extinguished; 15s extinguished; 5s extinguished; completely on open flame
5. Precision dyeing, Konica Minolta color measurement instrument CM-3600A accurate color measurement color production process
6. 850 °C burning heating metal parts by glow-wire test (GWIT 850 °C ), fastening screws pieces without cracking, ultrasonic welding strength, good toughness, high impact strength, corrosion resistance
Notes: different level, different price.
| PC/ABS-B110F-GWF850 property parameter table (Glow wire ignitability 850°C) | |||||
| Property item | Test condition | Test method | PC/ABS-B110F-GWF850 | Unit | |
| Physical properties | Specific gravity | ASTM D792 | 1.15 | ||
| Water absorption rate | ASTM D570 | 0.25 | / | ||
| Mould contraction rate | 3.2mm | ASTM D955 | 5-7 | E-3 | |
| Mechanical properties | Tensile strength (yield point) | ASTM D638 | 62 | Mpa | |
| Tensile rate (rupture point) | ASTM D638 | 25 | / | ||
| Tensile modulus | ASTM D638 | 2691 | Mpa | ||
| Flexural strength | ASTM D790 | 88 | Mpa | ||
| Flexural modulus | ASTM D790 | 2500 | Mpa | ||
| Impact strength (notched) | 23°C | ASTM D256 | 320 | J/m | |
| Hardness | Rockwell | ASTM D785 | 118 | R | |
| Thermal properties | Heat deflection temperature | 0.45Mpa | ASTM D648 | 115 | °C |
| Heat deflection temperature | 1.8Mpa | ASTM D648 | 104 | °C | |
| Coefficient linear thermal expansion | E831 | 4.00E-05 | 1/°C | ||
| UL long-term using temperature with impact | UL746B | 90 | °C | ||
| Glow wire ignitability | ASTM D2863 | 850 | °C | ||
| Flame retardant | UL94 | V0 | |||
Now, here are some pictures of our product:
For more information about our products and our company, please visit our website . We have great interest in developing business with you.
Or any questions, please contact us any time. We will try our best to satisfy your requirements.
Thanks for your continued support to Gangyangda, we will continue our efforts to do better, beyond the self.
Should you want to get more information of our products from our side, please do feel free to contact me. Here is my full contact information.
