Home > Products > New Products > LOW PRICE!!! PVC Laminated gypsum board/ceiling
LOW PRICE!!! PVC Laminated gypsum board/ceiling
- 10000 Square Meter / Square Meters per Month
- qingdao
- T/T
- Artificial stone marble tile decorative pvc edge trim
- Super Thin indoor artificial wall stone faux marble wall covering
- super thin artificial marble stone cornice
- artificial edge banding marble tile trim
- Wall Decoration Big Thin Artificial Quartz Stone 1220*2440MM
- Super Thin faux stone wall covering artificial stone wall panel
Product Details
Place of Origin: | Shandong, China | Brand Name: | atlantis | Model Number: | A171-2 |
Function: | Fireproof, Heat Insulation, Moisture-Proof, Mould-Proof, Smoke-Proof, Sound-Absorbing, Soundproof, Waterproof | Feature: | Artistic Ceilings, Honeycomb Ceilings, Integrated Ceilings, Perforated Ceilings | Ceiling Tile Shape: | Square |
Ceiling Tile Type: | PVC Ceilings |
Product Description
PVC Laminated Gypsum Ceiling Tiles
1) Material: paper-faced gypsum board PVC facing + aluminum foil backing
2) Thickness:7mm, 7.5mm, 8.0mm, 8.5mm,9.0mm, 9.5mm,10mm,12.0mm,
3) Sizes:
595mmX595mm
600mmX600mm(2'X2')
603mmX603mm
595mmX1195mm
600mmX1200mm(2'X4')
603mmX1210mm
4) Size tolerance: Length <+/-1.0mm, width < +/-1.0mm, thickness <+/-0.5mm
5) Weight: 7.5mm=5.7kg/sqm, 8.0mm=5.9kg/sqm, 8.5mm=6.2kg/sqm, 9mm=6.8kg/sqm, 9.5mm=7.1kg/sqm, 12mm=9.2kg/sqm, 12.5mm=9.5kg/sqm
6) Strength: >100N
7) Characters: Non-flammable B1, in accordance with Chinese standard GB8624-1997
8) Installation: Match with ceiling T-bar Packing: Export carton(6pcs,8pcs or 10 pcs per carton with film)
Certification:
China national quality standard; ISO9001:2000.
Acoustic PVC Ceiling Board
Perforated gypsum board acoustic ceiling board
It has sound absorbing functions besides the advantages of gypsum board.
Advantages of perforated gypsum board
*The perforated ceiling production line is a European technique and uses European equipment.
*It uses digital industrial technology which precisely controls the geometric patterns.
*It meets United States ASTM C1396 standards high-density gypsum board.
*Its painting uses a computer controlled system and low reflective coating to ensure no difference in color.
*It passes the national JCT803-2007 sound absorption of perforated gypsum board.
*Using a large laminating machine and sound-absorbing cloth of various colors.
*Standard packaging, excellent packaging design.
Common specification:
Code Number | Thickness(mm) | Width(mm) | Length(mm) |
G2400 | 9.5 | 1200 | 2400 |
Q2400 | 12 | 1200 | 2400 |
For other styles, we can customised according to quantity.
Square perforated style sheet
Type:G2400
Size of Square holes: 5x5mm, 10x10mm,12x12mm
Size(H*W*L): 12.5x1200x2400mm 12.5x600x600mm 12.5x600x1200mm
Back cover material: white, black, blue sound absorbing cloth
Punch area: H1,H2,H2L,H4,H4L,H6,H8 other punch can be ordered.
Weight: 9.4kg/punch
Punching rate: 13.4%
Acoustic performance: aw0.65 NRC 0.70 RH 70
Round-shape perforated style sheet
Type:Q2400
Diameter: 6mm,8mm,12mm,15mm
Size(H*W*L): 12.5x1200x2400mm 12.5x600x600mm 12.5x600x1200mm
Surface treatment: plain
Back cover material: white, black, blue sound absorbing cloth
Punch design: H1,H2,H3,H4,H6,H8 other designs can be ordered.
Weight: 9.4kg/square meter
Punching rate: 19.6%
Acoustic performance: aw0.65 NRC 0.70 RH 70
Contact info;
Tel:0086-539-2701062
Fax:0086-539-2701063
Mobile:0086-13969998845
Thanks for your time.
Frank Zhuo
Atlantis Decoration&Building Material CO.LTD is your best choice.
YOUR SUCCESS IS MY BUSINESS!!!
