Multilayer GPS Control PCB&PCB Assembly,smt,oem Service

Name: Multilayer GPS Control PCB&PCB Assembly,smt,oem Service
Brand: Hangzhou Singo
SKU: 118785517

US$ 1 - 100 MOQ: 1 Piece

Key Specifications

Place of Origin:

Zhejiang, China

Brand Name:

Hangzhou Singo

Base Material:

FR-4

Hangzhou Singo Tech Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shanghai

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Zhejiang, China

Brand Name Hangzhou Singo

Base Material FR-4

Copper Thickness 1 OZ

Board Thickness 1.6mm

Min. Hole Size 8mil

Min. Line Width 5mil

Min. Line Spacing 5mil

Surface Finishing according to your request

Specifications

PCB with multilayers by immersion gold surface finishing type
1.standard and environmental produce technology
2.nice price

Multilayer GPS control PCB&PCB assembly

1 We have much expereince in various of electrical product PCB design and assembly

2 We provide PCB assembly turkey service,OEM and ODM

3 Only BOM and Gerber file(PCB file) is needed

4 Strong component sourcing capability to achive low price

5 Production flow in accordance with technic and environmental requirment

6 Have internal conformal coating process

7 Programmable logic controller(PLC) test fixture is utilized to test electrical function of PCBA

8 100% final test

9 High quality ensured

1.Base material	FR-4 / High TG FR-4 / Lead free Materials (ROHS Compliant) / Halogen Free material /CEM-3/CEM-1/ /PTFE/ROGERS/ARLON/TACONIC
2. Layers	1~30
3. Finished inner / outer copper thickness	1~20 OZ
4.Finished board thickness	0.2~7.0MM
5.Max panel size	≤2sidesPCB: 6001500mm Multilayer PCB: 5001200mm
6.Min conductor line width/spacing	Inner layers: ≥3/3mil Outer layers: ≥3.5/3.5mil
7.Warpage	Board thickness≤0.79mm: β≤1.0% 0.80≤Board thickness≤2.4mm: β≤0.7% Board thickness≥2.5mm: β≤0.5%
8.Controlled Impedance	+/-5%
9.Surface treatment	OSP: 0.5-0.5um HASL: 2-40um Lead free HASL: 2-40um ENIG: Au 1-10U’’ ENEPIG: PB 2-5U’’/ Au 1-8U’’ Immersion Tin:0.8-1.2um Immersion silver: 0.1-1.2um Peelable blue mask Carbon ink Gold plating: Au 1-150U’’
10. E-testing pass percent	97% pass for the first time,+/-2%(tolerance)
11.Hole tolerance	PTH: +/-3mil NPTH: +/-2mil

Our equipments
1.Drilling workshop	4 drilling bits of drilling machine: 4 sets 2 drilling bits of drilling machine: 2 sets
2. photo plotting workshop	Israel “ORBOTECH” Photo Plotters
3.AOI	AOI machine
4.IPQC	“OXFORD” CMI 700 Copper Thickness Tester
5.Impedance test	USA “Tektronix” DSA 8200 Impedance Tester
6.Outline workshop	CNC routing machine: 7 sets angle-cutting machine V-cut machine
7.Testing Workshop	Surpass X-600: 2sets WTD FT-2808: 5sets WTD HV300: 1set
