carbonated juice filling machine / 3 in 1 juice machine
Feature:
1. The machine is mainly used in the beverage filling operations. The three functions of bottle washing, filling and capping are composed in one body of the machine.
2. It is automatic in total process and suitable for PET bottled juice tea drink which can resistant high temperature.
3. It also can be used for mineral water, pure water and many other no gas containing drinks.
4. It makes by high quality SUS304 and key parts are precision machined by NC tool.
5. The total machine adopts advanced photoelectric detection technology to detect each part's operation status, no bottle no filling, no bottle no capping, automatic easy operation.
6. Using the wind sent access, with clamp hanging the bottle neck which can keep the bottle shape high-speed.
7. Washing bottle mouth with special designed washing manipulator, clip in the bottle neck, stable avoid secondary pollution.
8. Filling uses lifting valve, adopts micro pressure filling principle to ensure correct filling.
9. Capping adopts French advanced technology, cap sorter install in a lower position, send cap in level position.
10. Host adopts advanced PLC automatic control technology, the key electrical components from famous company such as Japan Mitsubishi, France Schneider, Omron.
carbonated juice filling machine / 3 in 1 juice machine Main technical parameters
Model: |
RCGF16-12-6 |
RCGF18-18-6 |
RCGF24-24-8 |
RCGF32-32-10 |
RCGF40-40-10 |
||
capacity :500ml |
4000 |
6000 |
8000 |
12000 |
16000 |
||
bottle shape: |
roud or square |
||||||
PET bottle: (mm) |
(Bottle Diameter):φ50-.φ110mm (Height):150-340mm |
||||||
cap: |
Plastic srew cap |
||||||
filling precision: |
≤±5mm |
||||||
filling pressure:(Mpa) |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
0.15-0.35 |
||
rinsing pressure:(Mpa) |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
0.2-0.25 |
||
Filling volume :(L) |
0.5 |
3.5 |
4 |
6 |
8 |
||
overall size:(mm) |
2150*1400 |
2450*1800 |
2780*2200 |
3600*2650 |
3800*2950 |
||
weight: (kg) |
2500 |
3500 |
4500 |
5500 |
6500 |
||
carbonated juice filling machine / 3 in 1 juice machine photos :
