Biometric Fingerprint Access Control

* It’s with the most advanced fingerprint arithmetic in the world, Automatically analyze the tiny

difference of the latest fingerprints vs. the previous fingerprints and update accordingly to ensure

the high accuracy and the optimum speed of fingerprint recognition, the identification time is less

than 1 second.

* The device is built-in ID card sensor(optional for IC card), validate freely by Card, fingerprint

and password combination, access control is more flexible and securely.

* Support U disk to download or upload attendance records and fingerprint data ect. User could

enroll the fingerprint in one device, and share the enrollment information with other devices

through the USB flash memory .

* TCP/IP communication, network connection is simple and convenient, support Push

Technology, operate access control networking and data collection & share freely.

* With multi-level validation, anti-pass back and so on high-end functions of access control

* With tamper alarm, over-time door opening alarm and so on

* Authentication modes are 1:1 and 1:N, user can register ten fingers, max fingerprint capacity is

1,000 enrollment and 100,000 record

* With one set lock for output, two sets door release button, those could connect wire or wireless

switch.

* One group Wiegand 26/34 output

*Can setup P.segment, P group and access permission without connecting to PC.

* Support multi development language(VB, C++, C#,Delphi ect) SDK, and ODM/OEM

software development

* Support English, French, Spanish, Korean ect different languages.

Model

F151

LCD Screen

2.4 inch TFT (320*240) Color Screen

Fingerprint Sensor

Resolution

500DPI (Optical sensor)

Hardware Platform

AC2911

Algorithm Version

RSFv5.1

CPU

ARM926EJ CPU, Running Frequency: 200MHZ

Communication

TCP/IP,   RS485, USB Memory Disk

User Capacity

1,000 (optional to 2,000 or 3,000)

Records Capacity

100,000

Software OS

XP/Win2003/Vista/Win7/Win8 (32bit / 64bit)

Identification Time

< 1 S

Authentication Method

Fingerprint/ RFID Card (125Khz)(could customize   Mifare

card)/Password

Language

Chinese / English / Spanish/Portuguese/ German (could   customize

others)

Bell

Built-in timing bell(can connect to external timing   bell)

Access Control Interface

Wiegand26/34, Door Lock, Siren, Release Button(can   connect 2

groups), Doorbell, Door Sensor

Professional Access Function

Open door by multilevel verification, anti-pass back

Power

DC 12V/2A

FRR

<1%

FAR

<0.00001%

Operating Mode

Off-line/On-line

Authentication Mode

1:1, 1:N

Operating environment

Operating Temp: 0°C-50°C, Humidity:80%

Dimension(L*W*H)mm

Terminal - 181*91*36mm

Package – 246*164*71mm

Weight

Terminal – 0.48 Kg

Package – 0.812Kg
