Home > Metallurgy, Mineral & Energy > Ceramic Material > Alumina Ceramics > Cordierite Ceramic Parts

Cordierite Ceramic Parts

Name: Cordierite Ceramic Parts
Brand: JSET
SKU: 118706331
Availability: InStock

US$ 0.5 - 2 MOQ: 500 Pieces

Key Specifications

Get Latest Price

Place of Origin:

Shanghai, China

Type:

Ceramic Parts

Application:

Industrial Ceramic

Contact Supplier Request Quote Chat Now

Shanghai JS Electronics Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Place of Origin Shanghai, China

Type Ceramic Parts

Application Industrial Ceramic

Model Number cordierite ceramic parts

Brand Name JSET

Cordierite ceramic parts

The main chemical ingredient of cordierite is 2MgO·2Al2O3·5SiO2,main material is steatite,clay,alumina,feldspar,etc. Manufactured by normal ceramic technic,can be used for loop framework,insulators of arc-resistance,element of composite materials,burnable nozzle of electrical insulators,and etc.

JSET cordierite parts without cracking in the thin wall,can achieve tight tolerance request.

Cordierite material properties:

Item	Test Condition	Unit&Symbol	Cordierite ceramics
The main chemical ingredient			2MgO 2Al2O3 5SiO2
Bulk Density		gm/cc	2.5
Maximum Use Temperature			1000℃
Water absorption		%	0
Hardness		HV	800
Bending Strength	20° C	Kgf/cm2	900
Compressive Strength	20° C	Kgf/cm2	3500
Fracture Toughness	K(I c)	Map.m3/2	-
Coefficient of thermal expansion		1X 10^-6/°C	≤2.0
Coefficient of thermal conductivity	25° C-30° C	W/m °K	1.3-
Thermal Shock Resistance	Tc	°C	250
Dielectricity constant	1MHz.25℃		6
Dielectric strength		ac-kV/mm (ac V/mil)	10
Volume Resistivity	20℃	ohm-cm	> 10¹²

Any cordierite parts can be made by us please send us your technical drawing freely!

If you would like any further information or clarification of applications or bespoke design assistance ? please feel free to contact us and send us a inquiry.
