Help CenterSmall Front End Wheel Loader Price CS910
Related Products
Packaging & Delivery
Packaging Details:
1,For 1 or 2 ton mini wheel loader: one unit 1 or 2 ton mini loader put into one 20 GP’ CONTAINER, or two mini loaders put into one 40 HQ’ CONTAINER.
2, For 3ton, 5ton, 6ton wheel loader: one unit put into one 40HQ CONTAINER, Remove the bucket and uld drive in/out the cabin.easy to assemble up for customer.
Delivery Detail: wheel loader will be sent within 20 working days after recieving deposit or original L/C.
Factory details
Parameters and photo of details
Main parameters of CS 910
MODEL |
CS910 |
Overall Dimension(mm) |
4450/1430/2370(2000) |
Rated loading(t) |
1.0 |
Operating weight(kg) |
2690 |
Maximum Breakout Force(kN) |
35 |
Min.ground clearance(mm) |
230 |
Steering Angle(°) |
right and left 35 |
Min.swerve diameter(mm) |
3750 |
forward shift NO.1(km/h) |
0-7 |
forward shift NO.2(km/h) |
0-24 |
reverse shift NO.1(km/h) |
0-7 |
reverse shift NO.2(km/h) |
0-24 |
Engine model |
490BPG,EuroIII engine,Yangmar |
rated power/Rated speeds(kw/r/nin) |
32.4/2400 |
No.of cylinder-bore/stroke |
4/108/125 |
Rated bucket capacity(m3) |
0.54. |
Total time(S) |
9 |
Dump height fully raised(mm) |
2420 |
Reach fully raised (mm) |
850 |
Tyre type specification |
10/12.5 12-16.5 31*15.5-15 |
Width of tyre (mm) |
270 |
Track base (mm) |
1160 |
Wheel base (mm) |
1710 |
Maximum Speed (km/h) |
|
ATTACHMENTS(photos):
Company profile:
Jinan Fuman International Trade Co., Ltd has cooperation with Chinese top factories in area of construction machines and heavy duty trucks. We export mainly wheel loader, forklift, farm machinery, truck crane, excavator, road roller, motor grader, bulldozer, mining dump truck, tipper and etc, Our products have been exported to more than 70 countries and regions with high evaluation.
High quality and reasonable price are our promis to our clients.
Our service:
1.Reply your inquiry in 24 hours.
2.Experienced staffs answer all your questions professionally.
3.Provide customized design service.
4.Exclusive and unique solution can be provided to our customer by well-trained and professional engineers and staffs.
5.Special discount and protection of sales area provided to your distributor.
6.Warranty period is one year or against Bill of Lading.
