Home > Electrical & Electronics > Power Supply & Distribution > Voltage Regulator > DC/DC Adjustable Step up Converter 3-30V to 4-35V Charger Module for DIY Power Supply
DC/DC Adjustable Step up Converter 3-30V to 4-35V Charger Module for DIY Power Supply
US$ 1.7 - 1.85
MOQ: 50 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Geree
Model Number:
U002V
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
DC DC Boost Module Step up Converter 3.7V to 5V 1A USB Charger for Phone IphoneUS$ 0.1 - 3MOQ: 20 Pieces -
3.5-35V Converte to 5-56V DC DC Adjustable Boost Converter Charger Module Power SupplyNegotiableMOQ: 10 Pieces
-
DC10-32V to 12-35V 150W Boost DC-DC Converter ModuleNegotiableMOQ: 20 Pieces
-
3-30V to 4-35V DC Adjustable Boost Converter Charger Module for DIY Power SupplyNegotiableMOQ: 20 Pieces
-
LM2577 3-24V to 4-26V DC Adjustable Boost Converter Charger ModuleNegotiableMOQ: 20 Pieces
Place of Origin
Guangdong, China
Brand Name
Geree
Model Number
U002V
Current Type
DC
Specifications
LM2577 3-30V to 4-35V DC-DC Boost Converter Step Up Voltage Adjustable ModuleFeatures :
Modules nature: Non-isolated step-up (Boost)
Rectification: Non-synchronous rectification
Input voltage: 3V-30V
Output voltage: 4V-35V
Input current: 3A (max), No-load current 15mA
Power: 15W, if install heatsink can reach 20W (MAX), Please do not exceed 20W, or it would burn out.
Conversion efficiency: 92% (highest)
Switching frequency: 50KHz
Output ripple: 50mV (max)
Load regulation: ± 0.5%
Voltage regulation: ± 0.5%
Operating Temperature: -40 ° C to +85 ° C
Dimension: 48 x 23 x 14 mm
Short Circuit Protection: NONE
Applications:
DIY a mobile power supply
Boost charger
Power supply for electronic equipmentPackage
1 x DC-DC Boost Converter Step Up Voltage Adjustable Module (There is no User's Manual in the package.)
