wide degree 12V/24V Car vehicle Rear View Camera Back Up IR camera
Features:
Made of high quality and durable material
High-definition and wide viewing angles
Support color CMOS image
Support PAL/NTSC TV system
With good waterproof function
With its elegant and contemporary design, this camera is very popular
Specifications:
Effective pixels: pal--628 x 586, ntsc--510 x 496
Shutter speed: 1/50 pal, 1/60 ntsc 1/10,000 seconds
Mini. illumination: 0.1 Lux/F
Video output: RCA connector, 1.0vP-P,75ω
power consumption: 110mA, max. 300mA wiht IR on
Power supply: 12V/24V
Operating temperature: -20°C - 90°C, RH 95%
Storage temperature: -30°C - 80°C, RH 95%
Lens angle: 120 degree
Color: Black
Installation:
Mount the camera at the back of the car (on the license plate back window or other suitable place)
Connect the yellow video output connector to terminal display device
Connect the black power input connector to power output device
Connect the power of the camera to your reverse lights (If the camera is intended only for reversing) - red wire to positive and black wire to negative
Package Content:
1 x Color car rear view camera
1 x Power supply cable
1 x Video cable
