YX3000 Series Vvvf Speed Controller

YX3000 Series Vvvf Speed Controller thumbnail-1
YX3000 Series Vvvf Speed Controller photo-1
US$ 68 - 8,888 MOQ: 1 Unit
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
Yuanxin
Model Number:
YX3000
Contact Supplier Request Quote Chat Now
Shenzhen Yuanxin Electric Technologies Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
SHENZHEN
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Guangdong, China
Brand Name Yuanxin
Model Number YX3000
Output Power Other, 0.4kw-400kw
Output Type Other, Single/Triple
Input Voltage 220V/380V
Output Voltage 0~380V
Type Other, AC/DC/AC inverters
Output Frequency 0~500Hz
Output Current 0~850A

Specifications

YX3000 series vvvf speed controller
1. Fuji IGBT and TI DSP chip set.
2.low frequency torque

YX3000 series vvvf speed controller





YX3000 Series General Purpose Frequency Inverter is specially designed for variable frequency control and energy saving.



Instruction



YX3000 Series Sensor-less Vector Control Frequency Inverter is a function enhanced product with strong stability. It takes use of Fuji IGBT and the TI DSP chip set, completely optimizes vector control and V/F control. It has been widely deployed in various industrial environment, and special in situations requiring speed control precision pump torque response speed and low-frequency output.





Specification











Technical Features



  1. Two control modes: V/F control, and sensor-less vector control;
  2. Starting torque: 0.4Hz-20Hz;
  3. Internal brake unit has been deployed, and the braking resister can be connected outside for a quick stop;
  4. Five kinds of V/F control, which are constant torque V/F curve, One kind of customer defined V/F curve, 3 kinds of down torque curve (2.0/1.7/1.2 times the power).
  5. Through PLC or internal control terminal, multi-speed control and PID control could be realized. And users could combine a variety of operating modes while it’s necessary;
  6. Supporting multi-frequency deploy methods: digital setup, PID setup, analog quantity setup, and communication setup;
  7. Supports starting and stopping DC brake;
  8. YX3000 is Equipped with jump frequency control, which prevents mechanical resonance and makes the system more stable and reliable;
  9. YX3000 has build-in PI in order to establish close-loop control system easily;
  10. YX3000 is designed with the central frequency switch function, which let the end user to fix the central frequency while it is necessary;
  11. YX3000 has been equipped with RS485 communication interface, which support MODBUS protocol with ASCII and RTU forms;
  12. Working with water supply accessory to realize multiple-pump stable pressure water supply function.



Application



  1. Boiler drum, Induced draft fan, Mine exhaust fan;
  2. Energy-saving central air conditioning, Energy-saving air compressor
  3. Mechanical equipment, Conveyor
  4. Oil injection pump, Oil transfer pump;
  5. Circulating pump, water supply pump, constant pressure water supply;



Machine Size



Frequency Inverter Machine size and mounting size
Wall hanging type Machine size Mounting size Diameter of mounting hole(mm)
General type Fan,pump type H(mm) W(mm) D(mm) H1(mm) W1(mm)
YX3000-2S0004G   142 85 113 144 74 Φ5
YX3000-2S0007G
YX3000-2S0015G
YX3000-4T0007G YX3000-4T0015P 184 98 135 174 88 Φ5
YX3000-4T0015G YX3000-4T0022P
YX3000-2S0022G
YX3000-4T0022G YX3000-4T0037P 230 118 153 220 108 Φ5
YX3000-4T0037G YX3000-4T0055P
YX3000-4T0055G YX3000-4T0075P 280 181 183 267 100 Φ7
YX3000-4T0075G YX3000-4T0110P
YX3000-4T0110G YX3000-4T0150P 339 231 214 323 138 Φ8
YX3000-4T0150G YX3000-4T0185P
YX3000-4T0185G YX3000-4T0220P 423 258 230 407 195 Φ9
YX3000-4T0220G YX3000-4T0300P
YX3000-4T0300G YX3000-4T0370P 500 296 276 480 200 Φ10
YX3000-4T0370G YX3000-4T0450P
YX3000-4T0450G YX3000-4T0550P 560 320 269 538 217 Φ10
YX3000-4T0550G YX3000-4T0750P
YX3000-4T0750G YX3000-4T0900P 618 398 306 594 278 Φ12
YX3000-4T0900G YX3000-4T1100P
YX3000-4T1100G YX3000-4T1320P 760 485 324 736 322 Φ12
YX3000-4T1320G YX3000-4T1600P
