Specifications
Water Source Heat Pump1.new models developed by Hicool
2.characterized in high-efficiency and non-pollution.
Water Source Heat Pump
Water Cooled Packaged units are new models developed by Hicool, characterized in high-efficiency and non-pollution. Cooling and heating can be selected by purpose that reduces running cost. It combined the merits of both central air conditioners and home air conditioners, so the air conditioning room temperature can be adjusted separated or centralized.
Feature
Air Coil
Die formed plate type aluminium fins mechanically bonded to high efficiency inner grooved copper tubes.
Fans
Forward curved double inlet fans in involute scrolls and fitted directly to a resiliently mounted motor. Speed tappings allow airflow selection to match external duct pressure.
|
Packaged Horizontal Water Source Heat Pump Parameter | |||||||||
| Model | H-WP30B | H-WP36B | H-WP42B | H-WP60B | H-WP75B | H-WP95B | H-WP125B/3 | ||
| Cooling Capacity | kW | 3.0 | 3.6 | 4.1 | 6.1 | 7.8 | 9.2 | 13.0 | |
| Heating Capacity | kW | 3.1 | 3.7 | 4.2 | 6.3 | 8.0 | 9.3 | 13.3 | |
|
Rated Input Power |
Cooling | kW | 0.8 | 1.0 | 1.1 | 1.7 | 2.0 | 2.7 | 3.6 |
| Heating | kW | 0.9 | 1.1 | 1.2 | 1.8 | 2.1 | 2.8 | 3.7 | |
|
Rated Input Current |
Cooling | A | 3.6 | 4.6 | 5.1 | 8.1 | 9.6 | 11.5 | 6.1 |
| Heating | A | 3.9 | 5.0 | 5.5 | 8.6 | 10.0 | 11.7 | 6.3 | |
| Power Supply | 220V~/50Hz/1Ph | 380V~/50Hz/3Ph | |||||||
|
Compressor |
Type | Rotary |
Scroll |
||||||
| Quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Refrigerant | R22 | ||||||||
| Refrigerant Charge | kg | 1.2 | 1.4 | 1.6 | 2.0 | 2.2 | 2.7 | 3.0 | |
| Protection |
High/low pressure protection, over-heat protection, over-current protection, water break protection |
||||||||
| Air Flow Volume | m3/h | 550 | 600 | 850 | 1300 | 1600 | 1800 | 2400 | |
| Fan Power | W | 25 | 30 | 40 | 50 | 70 | 90 | 120 | |
| Static Pressure | Pa | 30 | 30 | 30 | 30 | 30 | 30 | 40 | |
| Cooling Water Flow | m3/h | 0.60 | 0.75 | 0.80 | 1.20 | 1.80 | 2.15 | 2.67 | |
|
Cooling Water Connecting Pipe |
DN20 | DN20 | DN20 | DN25 | DN25 | DN32 | DN32 | ||
| Water Resistance | kPa | 6.0 | 8.0 | 10.0 | 12.0 | 14.0 | 23.0 | 25.0 | |
| Noise | dB(A) | 38 | 39 | 41 | 43 | 45 | 47 | 48 | |
|
Net Dimension(LxWxH) |
mm | 1060×580×410 | 1060×580×410 | 1060×580×410 | 1144×645×480 | 1144×645×480 | 1144×645×480 | 1350×645×550 | |
| Net Weight | kg | 58 | 65 | 72 | 76 | 80 | 95 | 105 | |
|
Packing Dimension(LxWxH) |
mm | 1180×600×480 | 1180×600×480 | 1180×600×480 | 1260×665×550 | 1260×665×550 | 1260×665×550 | 1480×665×620 | |
| Gross Weight | kg | 62 | 69 | 76 | 80 | 85 | 100 | 110 | |
|
Note: 1) Nominal cooling conditions: indoor dry bulb: 27°C, indoor wet bulb: 19°C, cooling water inlet: 30°C, cooling water outlet: 35°C 2) Nominal heating conditions: indoor dry bulb: 20°C, indoor wet bulb: 15°C, cooling water inlet: 20°C, cooling water outlet: 15°C. 3) Applicable temperature range: 21-30°C 4) Manufacturer keeps the right to change the above parameter without prior notice | |||||||||
HUIZHOU HICOOL CLIMATE EQUIPMENT CO., LTDis an emerging company that specializes in the design and manufacture of commercial/central air conditioning system. HICOOL, committed itself to commercial/central air conditioner researching, developing & designing since 2003, is strategically located in Huizhou, a city by the beautiful Pearl River in Guangdong Province, China. HICOOL operates out of a new 25,000 square meters factory which was designed to employ the latest efficiencies in manufacturing process.
Customers benefit from HICOOL's state of art factory and product design utilizing cutting edge engineering technology. The company adheres to four key principles in the design and manufacture of its products namely: technology, efficiency, quality, and innovation. The company's specialized products meet its customer's needs by incorporating leading edge technology along with pursuing a quality policy of “reliability and safety, green and efficiency, innovation and technology, improvement and excellence”. The company's products demonstrate superior quality, elegant design, and extraordinary energy efficiency. Our factory possesses advanced production equipments and testing systems that are established to comply with the ISO9001 Quality Management System. All of the company's products are certified by CCC (China Compulsory Certification), CE & CB, while the leading products have MEPS (Oceania market), ETL (Northern American market), and some other certificates.
HICOOL provides its customer with custom design generated by computerized modeling and simulation. We partner with distinguished institutions and companies internationally to offer our customers free services in the design of air conditioning system, installation, training, and warranty.
High quality creates cool life. Our commitment to our customers, is to continue to add value through cutting edge technology, cost competitiveness, and sustainable growth.
