Home > Industrial Equipment & Components > Refrigeration Equipment > Industrial Air Conditioner > Horizontal Heat Pump Water Heater CE UL
US$ 362 - 900
MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Type:
Other, heat pump
Place of Origin:
Guangdong, China
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Low Power Consumption Air Conditioner Water Source Heat Pump CE UL GS QEC CBUS$ 362 - 900MOQ: 1 Set -
Mini Water Source Heat Pump Cooling Capacity 3kw~13kw Heating Capacity 3.1kw~13.3 CEUS$ 362 - 900MOQ: 1 Set
-
Packaged Horizontal Water Source Heat PumpUS$ 500 - 5,000MOQ: 1 Set
-
Packaged Water Source Floor Standing Heat Pump ( Water to Air Conditioner)US$ 1,800 - 7,950MOQ: 1 Set
-
Packaged Horizontal Water Source Heat Pump ( Water to Air Heat Pump)NegotiableMOQ: 1 Set
Condition
New
Type
Other, heat pump
Place of Origin
Guangdong, China
Brand Name
HICOOL
Model Number
H-WP60
Operating Voltage
230 VAC
Mounting
Wall / Window Mount
Certification
CE
After-sales Service Provided
Overseas service center available
Specifications
1)Cooling Capacity:3kw~13kw2)Heating Capacity :3.1kw~13.3kw
3)High effciency ,energy saving
Water Source Heat Pump Unit 1.High efficiency, energy saving, investment saving The water cooled packaged heat pump has higher efficiency than air cooled heat pump. If the system needs to supply cooling capacity and heating capacity at the same time, the unit can realize internal energy balance, reduce operation time of cooling tower and heating equipments to save energy. Meanwhile, comparing with traditional central air conditioners, this unit does not need special machine room or big air duct. 2.Easy to install, flexible application Simple design and installation, less control devices, easy to configure water pipe work, short designing period. Meanwhile, user can select cooling or heating according to different application conditions, or partial cooling with partial heating. 3.Separate measuring It can connect to user’s independent electric meter, convenient for separate calculation of electric charges, help to avoid conflict. 4.Introducing fresh air to improve air quality The system can introduce fresh air, exempt annoyance of air-condition disease. Application range: Widely applied to office buildings, apartments, hotels, banks, schools and gymnasiums etc. Packaged Horizontal Water Source Heat Pump Parameter | |||||||||
| Model | H-WP30B | H-WP36B | H-WP42B | H-WP60B | H-WP75B | H-WP95B | H-WP125B/3 | ||
| Cooling Capacity | kW | 3.0 | 3.6 | 4.1 | 6.1 | 7.8 | 9.2 | 13.0 | |
| Heating Capacity | kW | 3.1 | 3.7 | 4.2 | 6.3 | 8.0 | 9.3 | 13.3 | |
Rated Input Power | Cooling | kW | 0.8 | 1.0 | 1.1 | 1.7 | 2.0 | 2.7 | 3.6 |
| Heating | kW | 0.9 | 1.1 | 1.2 | 1.8 | 2.1 | 2.8 | 3.7 | |
Rated Input Current | Cooling | A | 3.6 | 4.6 | 5.1 | 8.1 | 9.6 | 11.5 | 6.1 |
| Heating | A | 3.9 | 5.0 | 5.5 | 8.6 | 10.0 | 11.7 | 6.3 | |
| Power Supply | 220V~/50Hz/1Ph | 380V~/50Hz/3Ph | |||||||
Compressor | Type | Rotary | Scroll | ||||||
| Quantity | 1 | 1 | 1 | 1 | 1 | 1 | 1 | ||
| Refrigerant | R22 | ||||||||
| Refrigerant Charge | kg | 1.2 | 1.4 | 1.6 | 2.0 | 2.2 | 2.7 | 3.0 | |
| Protection | High/low pressure protection, over-heat protection, over-current protection, water break protection | ||||||||
| Air Flow Volume | m3/h | 550 | 600 | 850 | 1300 | 1600 | 1800 | 2400 | |
| Fan Power | W | 25 | 30 | 40 | 50 | 70 | 90 | 120 | |
| Static Pressure | Pa | 30 | 30 | 30 | 30 | 30 | 30 | 40 | |
| Cooling Water Flow | m3/h | 0.60 | 0.75 | 0.80 | 1.20 | 1.80 | 2.15 | 2.67 | |
Cooling Water Connecting Pipe | DN20 | DN20 | DN20 | DN25 | DN25 | DN32 | DN32 | ||
| Water Resistance | kPa | 6.0 | 8.0 | 10.0 | 12.0 | 14.0 | 23.0 | 25.0 | |
| Noise | dB(A) | 38 | 39 | 41 | 43 | 45 | 47 | 48 | |
Net Dimension(LxWxH) | mm | 1060×580×410 | 1060×580×410 | 1060×580×410 | 1144×645×480 | 1144×645×480 | 1144×645×480 | 1350×645×550 | |
| Net Weight | kg | 58 | 65 | 72 | 76 | 80 | 95 | 105 | |
Packing Dimension(LxWxH) | mm | 1180×600×480 | 1180×600×480 | 1180×600×480 | 1260×665×550 | 1260×665×550 | 1260×665×550 | 1480×665×620 | |
| Gross Weight | kg | 62 | 69 | 76 | 80 | 85 | 100 | 110 | |
Note: 1) Nominal cooling conditions: indoor dry bulb: 27°C, indoor wet bulb: 19°C, cooling water inlet: 30°C, cooling water outlet: 35°C 2) Nominal heating conditions: indoor dry bulb: 20°C, indoor wet bulb: 15°C, cooling water inlet: 20°C, cooling water outlet: 15°C. 3) Applicable temperature range: 21-30°C 4) Manufacturer keeps the right to change the above parameter without prior notice | |||||||||
Finished products
HUIZHOU HICOOL CLIMATE EQUIPMENT CO., LTDis an emerging company that specializes in the design and manufacture of commercial/central air conditioning system. HICOOL, committed itself to commercial/central air conditioner researching, developing & designing since 2003, is strategically located in Huizhou, a city by the beautiful Pearl River in Guangdong Province, China. HICOOL operates out of a new 25,000 square meters factory which was designed to employ the latest efficiencies in manufacturing process.
HICOOL offers extensive range of commercial/central air conditioning system including non-refrigerant air conditioner, VRV system, high and low static duct unit, rooftop unit, air-cooled split type floor standing unit, small or modular air-cooled chiller, water / ground source heat pump, air source heat pump, swimming pool heat pump, air / water cooled screw chiller, air handling unit, fan coils, cassette type, etc. These products are well recognized domestically and internationally by our customers from East Europe, Middle East, South Africa, Oceania, North America and South America.
Customers benefit from HICOOL's state of art factory and product design utilizing cutting edge engineering technology. The company adheres to four key principles in the design and manufacture of its products namely: technology, efficiency, quality, and innovation. The company's specialized products meet its customer's needs by incorporating leading edge technology along with pursuing a quality policy of “reliability and safety, green and efficiency, innovation and technology, improvement and excellence”. The company's products demonstrate superior quality, elegant design, and extraordinary energy efficiency. Our factory possesses advanced production equipments and testing systems that are established to comply with the ISO9001 Quality Management System. All of the company's products are certified by CCC (China Compulsory Certification), CE & CB, while the leading products have MEPS (Oceania market), ETL (Northern American market), and some other certificates.
Customers benefit from HICOOL's state of art factory and product design utilizing cutting edge engineering technology. The company adheres to four key principles in the design and manufacture of its products namely: technology, efficiency, quality, and innovation. The company's specialized products meet its customer's needs by incorporating leading edge technology along with pursuing a quality policy of “reliability and safety, green and efficiency, innovation and technology, improvement and excellence”. The company's products demonstrate superior quality, elegant design, and extraordinary energy efficiency. Our factory possesses advanced production equipments and testing systems that are established to comply with the ISO9001 Quality Management System. All of the company's products are certified by CCC (China Compulsory Certification), CE & CB, while the leading products have MEPS (Oceania market), ETL (Northern American market), and some other certificates.
HICOOL provides its customer with custom design generated by computerized modeling and simulation. We partner with distinguished institutions and companies internationally to offer our customers free services in the design of air conditioning system, installation, training, and warranty.
High quality creates cool life. Our commitment to our customers, is to continue to add value through cutting edge technology, cost competitiveness, and sustainable growth.
