Water Heat Pump CE Approved

Specifications

water Source Heat Pump
-High Efficiency and Energy Saving
-Operating Stability
-Advanced Technology

                                                       Water Heat Pump



The Water Heat Pump   is especially suitable for the building which has plenty of surplus heat, or the indoor area needs cooling and outdoor area needs heating. It is also suitable for the area where supplies adequate heat sources, like solar, river, lake and well water and terrestrial heat. It is also good for renovation of air conditioning for the old building.



Feature

-High Efficiency and Energy Saving:  The air conditioner unit can automatically adjust the output energy based on the actual load in the room, leading to saving of energy and reduction of operation costs.
-Operating Stability: The temperature of water maintains relatively steady during all four seasons in a year,making operation of the unit to become much more reliable and stable,basically not affected by the surrounding environment and the natural climate.
-Advanced Technology:  The unit provides not only air conditioning and heating, but also hot water for everyday life, making it really useful for multiple purposes.
-Split Operation:  Control is made much easier and simpler by using the combination of wire controland remote control.





Water Heat Pump  Parameter
Model			H-30WR	H-40WR	H-50WR	H-70WR	H-90WR	H-110WR	H-150WR
Cooling Capacity		kW	30	40	50	70	90	110	150
		103kcal/hr	25.8	34.4	43	60	78	95	129
Heating Capacity		kW	33.4	44.5	56.1	81.7	96.3	124.7	176
		103kcal/hr	28.7	38	48	70	83	107	151
Compressor	Type		Scroll Compressor
	Cooling Input Power	kW	4.8	6.5	8.5	12.5	13.7	19.9	26.6
	Heating Input Power	kW	6.8	9.1	11.5	16.7	19.5	26.7	35.7
	Quantity	Sets	2	2	2	2	4	3	4
	Power Supply		380V3~N/50Hz
Condense	Water Resistance	kPa	15	20	20	25	25	28	32
	Water Flow	m3/h	6.5	8.6	10.8	15.1	19.4	23.7	32.3
	Gap Spec	DN	32	40	50	50	50	65	65
Evaporator	Water Resistance	kPa	16	15	18	24	17	22	30
	Water Flow	m3/h	5.2	6.9	8.6	12	15.5	18.9	25.8
	Gap Spec	DN	32	40	50	50	50	65	65
Controller	Control Manner		Fully Automatic
	Protection		High/low pressure protection, freezing-proof/over-heat protection(dual), safety valve, over load protection, open phase/reverse phase protection, under voltage/over voltage protection, water-break protection
Dimension	Length	mm	800	1250	1300	1550	1400	1380	1750
	Width	mm	600	750	750	750	1420	1150	1420
	Height	mm	720	1330	1360	1430	1360	1430	1430
Weight		kg	180	330	420	520	610	710	850
Operation Weight		kg	200	350	450	550	650	750	900
Note: 1) Unit cooling capacity is decided according to the following conditions: Chilled water inlet: 12ºC, cooling water inlet: 18ºC, cooling water: 29ºC, condenser water inlet:    15-30ºC 2) Unit heating capacity is decided according to the following conditions: Coldd water inlet: 15ºC, hot water inlet: 40ºC, hot water outlet: 45ºC, evaporator water inlet: 12-22ºC 3) Water side dirt coefficient: 0.086m2 ºC/kW 4) Evaporator/condenser water side rated pressurer: 1.0Mpa 5) We can redesign for you if the above models can not reach your request.
