Factory Air Conditioner

Factory Air Conditioner thumbnail-1
Factory Air Conditioner photo-1
US$ 1,430 - 15,000 MOQ: 1 Piece
Key Specifications
Get Latest Price
Condition:
New
Type:
Cabinet Air Conditioner
Place of Origin:
Guangdong, China
Contact Supplier Request Quote Chat Now
Huizhou Hicool Climate Equipment Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen of China
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Type Cabinet Air Conditioner
Place of Origin Guangdong, China
Brand Name HICOOL
Model Number H-RtR525
Operating Voltage 380/400 VAC
Mounting Floor Standing
Certification CE
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Factory Air Conditioner
-commercial air conditioner unit
-High quality
-CE certificate

                                                                                               Factory Air Conditioner

1. It is packaged air conditioner which integrates condensing part, evaporating part & control part into a whole unit, firstly promoted & applied in South America, North Europe & Australia. 2. It is air cooled direct evaporation & expansion air conditioner, has no need on cooling water & chilled water system, dispenses with cooling tower/cooling water pump/chilled water pump,  relative pipe work, electric control & terminal equipments, saves user investment.

3. It integrates evaporating part & condensing part into a whole unit which is installed outside to save indoor space, user will only need to install the duct, no need to connect refrigerant pipe work, it works under intellectual control without special care.

Application range:

It is mainly applied to factories, schools, auditoriums, warehouses, etc.

Factory Air Conditioner





Rooftop Packaged Unit Parameter
 Model H-RtR175 H-RtR210 H-RtR260 H-RtR350 H-RtR525
Cooling Capacity kW 17.5 21 26 35 52.5
Cooling Input Power kW 6.4 7.8 9.6 12.9 16.7
Heating Capacity kW 19.3 23.0 28.5 38.5 57.8
Heating Input Power kW 6.3 7.4 9.5 12.4 16.2
Rated Air Flow Volume m3/h 3700 4200 5200 6600 9200
Max Static Pressure Pa 300 300 300 500 500
Compressor  Type  Scroll
Quantity 1 1 2 2 2
Power Supply  208-230V/3N/60Hz
Refrigerant R22(please inform us for R410A)
Refrigerant Charge kg 3.8 4.2 6 9.2 13.8
Noise dB(A) 59 61 61 63 65
Net Dimension(LxWxH) mm 1240×1000×810 1150×1050×1043 1310×1050×1135 2100×1210×1135 2100×1700×1135
Net Weight  kg 205 280 340 520 800
Packing Dimension(LxWxH) mm 1270×1050×865 1250×1150×1143 1410×1150×1290 2165×1295×1290 2165×1785×1290
Gross Weight  kg 225 320 380 550 845

 Model H-RtR610 H-RtR700 H-RtR875 H-RtR1050 H-RtR1225
Cooling Capacity kW 61 70 87.5 105 122.5
Cooling Input Power kW 19 20.4 31.5 38.5 43.8
Heating Capacity kW 65.4 77.0 96.3 115.5 134.8
Heating Input Power kW 18.3 19.6 31.1 37.2 43.4
Rated Air Flow Volume m3/h 10700 12300 15200 18300 21600
Max Static Pressure Pa 500 500 600 600 600
Compressor  Type  Scroll
 Quantity 2 2 2 4 4
Power Supply  208-230V/3N/60Hz
Refrigerant R22(please inform us for R410A)
Refrigerant Charge kg 15.2 16.4 16 26 30
Noise dB(A) 66 70 72 75 78
Net Dimension(LxWxH) mm 2210×1800×1210 2100×1995×1135 2803×2195×1123 3385×2193×1127 3800×2193×1127
Net Weight  kg 880 950 1240 1420 1610
Packing Dimension(LxWxH) mm 2310×1900×1310 2165×2080×1290 2903×2300×1223 3485×2300×1227 3900×2300×1227
Gross Weight  kg 925 1030 1330 1520 1720
Note:
1)Nominal cooling conditions: indoor dry bulb temperature is 27°C, indoor wet bulb temperature is 19°C, outdoor dry bulb temperature is 35°C, outdoor wet bulb temperature is 24°C.
2)Nominal heating conditions: indoor dry bulb temperature is 20°C, indoor







Factory Air ConditionerFactory Air ConditionerFactory Air ConditionerFactory Air Conditioner
