Home > Products > New Products > HONLE relay type automatic voltage stabilizer circuit diagram
HONLE relay type automatic voltage stabilizer circuit diagram
USD $1 - $200
/ Piece
10 Pieces(Min.Order)
- 30000 Piece / Pieces per Month
- NINGBO/SHANGHAI
- T/T Credit Card
You May Like
Product Details
| Place of Origin | Zhejiang, China | Brand Name | HONLE | |
| Model Number | DER, DER | Usage | Other, Other, STABILIZE VOLTAGE | |
| Phase | Single Phase | Current Type | Other, AC, AC |
Product Description
HONLE DER Relay type voltage stabilizer
Feature
This series automatic voltage regulator is a kind of delay control stabilizer,it owns wide input voltage range,compact size,light in weight,delay output,little wave distortion and reliable,strict design and accurate assemble.This kind of stabilizer can add voltage regulating function also.
Technical Features
1.Input voltage:150-270V
2.Output voltage:220V+/-8% 110V+/-10%
3.Delay output time:3-7 min /3-7 sec
4.Frequency:50/60Hz
Model | Power | DER-500VA | DER- 1000VA | DER- 1500VA | DER-2000VA | DER- 3000VA | DER- 5000VA |
| Input | Phase | Single Phase | |||||
| Voltage | AC150-270V | ||||||
| Frequency | 50Hz/60Hz | ||||||
| Output | Voltage | 220V+/-8%,110V+/-10% | |||||
| Efficiency | 98% | ||||||
| Frenquency | 50Hz/60Hz | ||||||
| Over voltage protection | AC246V+/-4V | ||||||
| Protection | Under-volt | Optional | |||||
| Over-volt | Optional | ||||||
| By pass | Optional | ||||||
| Delay | 3-7min/3-7sec | ||||||
| Over load/short circuit | Yes | ||||||
| Environment | Operating temperature | -10~40℃ | |||||
| Storage temperature | -15~45℃ | ||||||
| Humidity | 20% to 90% | ||||||
| Packing | Pcs/carton | 8 | 8 | 4 | 4 | 1 | 1 |
| Machine size(cm) | 24.5*11.6*15.7 | 24.5*11.6*15.7 | 29*17*22 | 29*17*22 | 40*25*29 | 40*25*29 | |
| Package dimension(cm) | 48.5*25.5*17.5 | 48.5*25.5*17.5 | 35.5*30*46 | 29*17*22 | 42*26*31 | 40*25*29 | |
