Condition
New
Type
Evaporative Air Cooler
Place of Origin
Guangdong, China
Brand Name
HICOOL
Model Number
h-ACH65T3
Operating Voltage
380/400 VAC
Mounting
Floor Standing
Certification
CE
After-sales Service Provided
Engineers available to service machinery overseas
Specifications
-Modular design-Fully-automatic control
-Intelligernt defrosting
-Convenient operation
swimming pool water chiller
1.Air to water air conditioning system saves investment
Compared with traditional water cooled central air conditioner, air to water system does not need the whole cooling water system, nor the special machine room, can save building space greatly, save civil engineering expenditure, reduce the total project investment.
2.Classical design, easy application
Modular air cooled chiller units adopt widely acceptable modular structure design, customers can combine multiple modules to run according to different working conditions, so that the system will have high efficiency no matter under full load or partial load, meanwhile, multiple modular units can start hierarchically without big initial current shock, furthermore every module has load balance function, the units can automatically select running multiple modules or running alternately, so that the total operation life & system reserve can be improved greatly.
3.Excellent performance, stable & reliable quality
The unit adopts world famous brand scroll compressor, configured with high efficiency low noise vibration absorption fan special for air conditioner, running smoothly & silently. Water side shell and tube heat exchanger has high efficiency, good freezing-proof protection, not easy to be blocked, but easy to clean. The units all have passed strict performance matching test to insure good stability & reliability.
Application range:
Meets all kinds of industrial & commercial requirements, especially applicable to villas, hotels, hospitals, office buildings, places of entertainment, restaurants, etc.
Parameter
| Model | H-Ach45T/3 | H-Ach55T/3 | H-Ach65T/3 | H-Ach88T/3 | H-Ach108T/3 | ||
| Cooling Capacity | kW | 45 | 55 | 65 | 84 | 103 | |
| Heating Capacity | kW | 47 | 57 | 68 | 88 | 108 | |
| Rated Input Power | Cooling | kW | 13.74 | 16.67 | 22.25 | 25.81 | 34.25 |
| Heating | kW | 13.54 | 16.56 | 21.71 | 26.56 | 34.73 | |
| Rated Input Current | Cooling | A | 23 | 27 | 36 | 44 | 56 |
| Heating | A | 23 | 28 | 37 | 44 | 58 | |
| Power Supply | 3N 380V 50Hz | ||||||
| Compressor | Type | Scroll Type | |||||
| Quantity | 4 | 4 | 4 | 2 | 2 | ||
| Fan Quantity | Sets | 2 | 2 | 2 | 2 | 2 | |
| Refrigerant Charge | kg | 14 | 16 | 18 | 24 | 32 | |
| Refrigerant | R22(please inform us for R410A) | ||||||
| Ambient Temperature | -7°C~43°C | ||||||
| Control Manner | Central control and network control | ||||||
| Protection | High/low pressure protection, freezing-proof protection, over-current protection, water-break protection | ||||||
| Noise | dB(A) | 60 | 61 | 63 | 65 | 66 | |
| In/Out Water Gap Spec | DN50 | DN65 | DN65 | DN125 | DN125 | ||
| Net Dimension(LxWxH) | mm | 1800×890×1615 | 2000×1000×1800 | 2000×1000×1800 | 2160×1280×2100 | 2160×1460×2110 | |
| Net Weight | kg | 560 | 650 | 780 | 1020 | 1290 | |
| ross Weight | kg | 595 | 690 | 825 | 1080 | 1380 | |
| Note: 1) Nominal cooling conditions: condenser air inlet dry bulb temperature: 35°C, wet bulb temperature: 24°C, evaporator water inlet temperature: 12°C, water outlet temperature: 7°C 2) Nominal heatling conditions: outdoor dry bulb temperature: 7°C, wet bulb temperature: 6°C, evaporator water inlet temperature: 40°C, water outlet temperature: 45°C | |||||||
Finished products
HUIZHOU HICOOL CLIMATE EQUIPMENT CO., LTDis an emerging company that specializes in the design and manufacture of commercial/central air conditioning system. HICOOL, committed itself to commercial/central air conditioner researching, developing & designing since 2003, is strategically located in Huizhou, a city by the beautiful Pearl River in Guangdong Province, China. HICOOL operates out of a new 25,000 square meters factory which was designed to employ the latest efficiencies in manufacturing process.
HICOOL offers extensive range of commercial/central air conditioning system including non-refrigerant air conditioner, VRV system, high and low static duct unit, rooftop unit, air-cooled split type floor standing unit, small or modular air-cooled chiller, water / ground source heat pump, air source heat pump, swimming pool heat pump, air / water cooled screw chiller, air handling unit, fan coils, cassette type, etc. These products are well recognized domestically and internationally by our customers from East Europe, Middle East, South Africa, Oceania, North America and South America.
Customers benefit from HICOOL's state of art factory and product design utilizing cutting edge engineering technology. The company adheres to four key principles in the design and manufacture of its products namely: technology, efficiency, quality, and innovation. The company's specialized products meet its customer's needs by incorporating leading edge technology along with pursuing a quality policy of “reliability and safety, green and efficiency, innovation and technology, improvement and excellence”. The company's products demonstrate superior quality, elegant design, and extraordinary energy efficiency. Our factory possesses advanced production equipments and testing systems that are established to comply with the ISO9001 Quality Management System. All of the company's products are certified by CCC (China Compulsory Certification), CE & CB, while the leading products have MEPS (Oceania market), ETL (Northern American market), and some other certificates.
Customers benefit from HICOOL's state of art factory and product design utilizing cutting edge engineering technology. The company adheres to four key principles in the design and manufacture of its products namely: technology, efficiency, quality, and innovation. The company's specialized products meet its customer's needs by incorporating leading edge technology along with pursuing a quality policy of “reliability and safety, green and efficiency, innovation and technology, improvement and excellence”. The company's products demonstrate superior quality, elegant design, and extraordinary energy efficiency. Our factory possesses advanced production equipments and testing systems that are established to comply with the ISO9001 Quality Management System. All of the company's products are certified by CCC (China Compulsory Certification), CE & CB, while the leading products have MEPS (Oceania market), ETL (Northern American market), and some other certificates.
HICOOL provides its customer with custom design generated by computerized modeling and simulation. We partner with distinguished institutions and companies internationally to offer our customers free services in the design of air conditioning system, installation, training, and warranty.
High quality creates cool life. Our commitment to our customers, is to continue to add value through cutting edge technology, cost competitiveness, and sustainable growth.
