Waterproof 12mm WS2811 RGB LED Pixel/LED Pixel Light
Features:
The led lamp diameter is 12mm, punching 12mm hole.
It’s cuttable.
According to the signboard hanging height, the distance between lamps should be within 5-8cm.
This lamp use special optical lens, high light transmittance. protect chip from moist, Unti-UV, thermostability, cold-resistant, anti-corrosion, and anti,acid-base, etc, more longer life time.
Operation Instructions:
50pcs of each string, 3A/string. User can use paralleling for multiple strings, each string running a loop, to avoid the nonuniform color which caused by the voltage drop, the thickness of power cord should not less than 2.5mm2.
Keep it in a well-ventilated environment, which good for heat dissipation.
The Green wire is data, Red wire connect with positive pole on the power supply, yellow wire connect with negative pole and controller’s GND port, green wire is connect to controller DAT port. Do not reversal!
Specification:
| Products Name | LED Pixel Light |
| Model NO. | PL12MM-R |
| Power Consumption | 0.1W |
| Work Voltage | DC5V |
| Work Current | 20mA |
| Beam Angle | 120°-140° |
| LED Encapsulation | Straw Hat LED |
| LED Quantity | 1pcs |
| LED Type | Low power LED |
| Color | Full Color |
| FPC Color | White |
| Dimension | Diameter12mm |
| Waterproof Grade | IP66 |
| Work Temperature | -30-60deg |
| Light Decay | Less Than 1% |
| Life-span | 30,000H |
| Certificate | CE&ROHS |
| Every Bag | 50pcs |
| Warranty | 3 years |
Products Applications:
channel letter backlighting
spurts draws light
advertisement sign light
indoor and outdoor illumination
architectural decorative lighting
Survice:
1. For all your inquires about us or our products, we will reply you in detail within 24 hours
2. We own well-tranied and professional sales & after- sale services who can speak fluent Engligh language
3. We offer OEM or ODM services. Can print clients'logo on product , can customize the retail box packing and other things.
4. We have very experienced R&D engineers and we have strong ability to do ODM projects.
