LT-XH50 500mA/50KW High Frequency medical x ray machine price

Main Features

1.High precision control mode through analog & digital double-loop control: Adopting HF (≥30kHz)inverter circuit combined with analog & digital double-loop control mode (composed of microprocessor and PWM dedicated chip), in order to achieve high-precision high voltage output. Though power supply fluctuation may appear, steady x-rays can still be output.
2.High-precision control in radiography time: Minimum exposure time is 0.0025 second, and quick radiography is accessible at any time without the influence of power phase, thus high-quality images are easily achieved and x-ray radiation to patients is reduced.
3.High-precision tube current control: X-ray tube current using two high-frequency converter heating which is controlled by the microprocessor high-speed A / D converter sampling tube current calculate in real-time. The microprocessor control the allowed load of the X-ray tube. It can set the most suitable radiography condition for the x-ray tube.
4.Various setting ways of Radiography conditions: you can select kV, mA and mAs to set the conditions for radiography, the program of the body parts is efficient, simplify operation., limit the select of three parameters for protecting the capacity according to the capacity of x-ray tube.
5.Self-protection, self-diagnosis: Once the malfunction happen, generator start self-protection, give an alarm. The malfunction can be detected via error code, convenient for maintenance.
6.Compact structure, Reduces installation space

The Most Cost-Effective Medical X-ray Machine in China

1. 50KW//30KHz: High frequency machine can cover all body parts, undertake general radiography and obtain clear images.
2. There is no other x-ray machine more cost-effective in the world. Moreover, you will sure be pleasantly surprised by the ultra-low price.
3. If you have mobile DR flat, that will be fantastic! A slight upgrade can help you realize direct digital imaging.
4. Its solid & streamline shape, as well as its ultra-long service life, make it well worth the cost.
5. With microcomputer control program and auto-generation of radiography conditions, It’s easy to operate and has good repeatability.

Technical index of main components :

Function: Common radiography, bucky radiography, single-table single tube
1.Maximum output power
Intermittent mode: 100kV ,500mA,50kW.
2.Adjustment range of tube current tube voltage
tube current: Radiography 32mA~630mA.
tube voltage: Radiography 40kV~125 kV.
3.Exposure Time:photography0.0025s~6.4s step adjustable
4 Nominal Frequency≥30kHz
5.The condition of power
Power Voltage:380V±10% 50Hz±10%
Power supply capacity: 120% the power of the equipment
Internal resistance:≤0.5Ω.
6.High frequency and high voltage x-ray generator(including microcomputer control console)
Nominal frequency of high voltage x-ray generator≥30kHz.
Internal resistance: less than 0.5Ω.
Nominal Output power:50kW.
Output Voltage: Radiography: 40 kV~125kV, step 1kV;
Output Current: Radiography: 32mA~630mA,
Exposure Time: 3ms~6.s.
Display:digital pipe display photography voltage Photography current photography time mAS of photography
X-ray tube
power:Small focus:30kw ;Big focus:50kw
Small focus:1.0mm ;Big focus:2.0mm
Speed of anode rotating:2800r/min
Anode heat capacity:150KHU
7.Collimator
Collimator with fixed position lamp.
Power supply: Working voltage: 24V
8.Radiography table
Integration of the table with stand column without skyrail design.
Length*width*height of table surface:2000mm×750mm×690mm. Deviation:±10mm
Distance from table surface to film:50mm
Horizontal movement range of table≥200mm
Vertical movement range of table≥900mm
has locking function, electromagnetic braking, Braking force:≥98N
9.X-ray source component pillar:
With scale that can indicate the height of the x-ray tube unit
Distance of vertical movement:800-1100mm±10mm;
Moving crosswise (left & right):+180°~-180°, deviation<±2°
Moving lengthways (along ground railway) ≥600mm
10.Bucky: Fixed beam filtration grid density≥40 lines/cm.
grid ratio 10:1,Focus Distance:110cm
11. Horizontal movement of bucky ≥500mm
Electromagnetic braking
Braking force ≥98N,
Button control
12. Collimator open and closedown should be flexible, reliable,can adjust to any Radiation in field rectangle size.
13. Stand chest stand
Fixed beam filtration grid density≥40 lines/cm.
Ray-filter grid:grid ratio 10:1, Focus Distance:100cm
Cassette size:5″×7″8″×10″10″×12″11″×14″14″×17″

Product Configuration:

X-ray tube, 1 set
Radiography Table 1 set
Collimator 1 set
High-voltage generator, 1 set
Microcomputer console, 1 set
High-voltage cable, 2 pieces
Vertical bucky stand 1 set

Factory

√ Quality Workplace

√ Good Labor relations

√ testing equipment

Team

√ Speak fluent English

√ Well-trained and professional sales

√ More than 10 years of experience engineers

Where are our customers?

We have sold LT-XH50 500mA/50KW High Frequency medical x ray machine to more than 50 countries ,like The Democratic Republic of Congo, Saudi Arabia, Nigeria, Zambia, Angola, Egypt, Kenya, Ghana, Paraguay, Nepal and Myanmar and so on.

Your satisfaction is our duty! It will be our great honor to serve you.

Q:Are you a trading company or do you are factory?

A:We are a factory and trade all in one company specialized in producing and providing a full package of hospital equipment, clinic equipment, vet hospital equipment and lab equipment for customers all around the world.Meanwhile We have close and long-term relationship with many other medical manufacturers which can offer you highest quality products and the most competitive price.

Q:What’s the minimum order quantity (MOQ)?

A:For most of our medical products, even order for only one unit is warmly welcomed and all customers are treated equally, efficiently and professionally. Please visit ourProducts page for more details.

Q: Can you do OEM/ private label?

A: Of course we can do OEM/private label for you.

Q: What’s your delivery time?

A: Generally it is 10 days if the goods are in stock. or it is 15-20 days if the goods are not in stock, it is according to quantity.

Q: How to ship the order?

A: Please inform us your instruction, by sea, by air or by express, any way is ok for us. We have very professional forwarder to provide the best shipping cost, service and guarantee.

Q: What is your terms of payment ?

A: We accept T/T ,LC,Western Union ,Escrow ,Paypal and more.Please suggest your preferred payment method.
