LTS-9 CE Medical Portable Ultrasound Scan Machine

Specifications

LTS-9 Laptop Ultrasound B scanner

Feature: -15 inch LED screen, pretty, portable and light

        -2 probe connector

-Full digital imaging technology, crystal-clear Image

    -3D Image function(optional)

-PC based, abundant functions

        -Powerful image and report management

-Large volume storage image and cineloop

      -DICOM display and transfer

-Compatible with laser/inkjet printers

      -Built-in battery(Work 5 hours)

Specification: -Maximum Scanning Depth: max. 250mm

                     -Multi-frequency: 5 segment frequencies

-Cine Loop: max. 1024 frames

                                       -Scanning mode: B, 2B, B/M, M, 4B, 9B, ZOOM;

  -Real-time Zoom on B mode

                                          -Image gray scale: 256 level gray scale

-Image processing: Pre-processing, after-processing, dynamic range, frame rate,  line average, edge;   enhancement, Black/White inversion; Gray scale adjustment, contrast, brightness, γ revision.

-Gain: 0-100dB; Time gain control(TGC): 8 segment adjustment, B, M adjustment separately.

-Measurement and calculation(human):

  B mode: distance, circumstance, area, volume, angle, ratio, stenosis, profile, histogram;

  M mode: heart rate, time, distance, slope and stenosis;

  Gynecology measurement: Uterus, cervix, endometrium, L/R ovary;

  Obstetric: gestation age, fetal weight, AFI;

  Cardiology: LV, LV function, LVPW, RVAWT;

  Urology: transition zone volume, bladder volume, RUV,   prostate, kidney;

  Small parts: optic, thyroid, jaw and face.

  Veterinary:  Cattle: BPD, CRL, TD;  Horse: GA; Dog: GS; Cat: HD, BD;  Sheep: BPD, CRL, TD

-Supported output apparatus: U-Disk, Laser/ink printer, video printer, VGA

-Zoom: 10 ratio, 1.5, 2.0, 2.5, 3.0, 3.5, 4.0, 4.5, 5.0, 5.5, 6.0

-Image store: by hardisk or USB disk

-3D image function(function): can get rebuilt 3D image by any probe

-Work time by built-in battery: about 5 hours

-Monitor: 15 inch color LED screen

                                  -Probe Connector:2

-Dimension: 362mm×340mm×60mm

        -Weight: Around 4.8Kg

Standard Configuration:  One Main Unit, One Convex probe(3.5MHz), One Power adapter.

Optional:  Linear, Trans-vaginal, Micro-convex,Rectal Probe; Bag; Trolley; Laser Printer.

Who we are ?

Our Leyte Electronic Co., Limited is a leading exporter and supply chain service provider for LTS-9 CE medical portable ultrasound scan machine

Our main products include X-ray machine, B ultrasound scanners, ECG, patient monitor, ICU equipment, Lab equipment, and other related medical disposables.

We have exported to more than 50 countries and built long term partnerships with clients of LTS-9 CE medical portable ultrasound scan machine

Our customer

Trade Term

1. This offer is valid with 30 days.

2. Delivery time: In 10 days after receive the payment

3. Item of payment: T/T ,LC,Western Union ,Escrow ,Paypal total payment before delivery

4. Carton box

Delivery detail:

1.We ship goods by UPS/DHL/FEDEX/TNT express takes 3~ 5 days to arrive , which is door to door ,you no need go out can get LTS-9 CE medical portable ultrasound scan machine

2.We can also help you ship by air cargo, it takes about 2-7 days to arrive, while you need to go to Air port to take LTS-9 CE medical portable ultrasound scan machine

3.If goods are large quantity and you need not so urgently ,you can choose by sea to save some freight cost which takes you about one month to get LTS-9 CE medical portable ultrasound scan machine

No matter what delivery way ,depending on your actual requirements.

Our services:

1. For all your inquires about us or our LTS-9 CE medical portable ultrasound scan machine , we will reply you in detail within 24 hours

2. We own well-tranied and passional sales & after- sale services who can speak fluent Engligh language

3. We offer OEM services. Can print your own logo on LTS-9 CE medical portable ultrasound scan machine , can customize the retail box packing and other things.

4. We have very experienced engineers ,can help you better use LTS-9 CE medical portable ultrasound scan machine
