Specifications
1,galvanized barbed rope2,Single,Double Strand
3,Zinc Coating:8-60g/m2
4,Barb Length:2cm
5,Barb Distance:5"...
Products introduction: thorn rope also ia called thorn mesh,it is a new type fencing mesh. Thorn rope is weaved by the corrosion-resisting galvanized steel plate or stainless plate material. Fix,beautfull,.good fencing ability and good frighten effect. thorn rope is mainly used in grassland verge,railway,and highway.etc.
-------
specification :
Razor blade specification :
Reference number |
Thickness (mm) |
Wire dia (mm) |
Barb length (mm) |
Barb Width (mm) |
Barb spacing (mm) |
BTO-12 |
0.5±0.05 |
2.5±0.1 |
12±1 |
13±1 |
26±1 |
BTO-15 |
0.5±0.05 |
2.5±0.1 |
15±1 |
15±1 |
33±1 |
BTO-20 |
0.5±0.05 |
2.5±0.1 |
20±1 |
15±1 |
34±1 |
BTO-22 |
0.5±0.05 |
2.5±0.1 |
22±1 |
15±1 |
34±1 |
CBT-65 |
0.6±0.05 |
2.5±0.1 |
65±2 |
21±1 |
100±2 |
Barbed tape wire specification :
Outside diameter |
No.of Loops |
Stand length per coil |
type |
notes |
450mm |
33 |
8m |
CBT-65 |
Single coil |
500mm |
41 |
10m |
CBT-65 |
Single coil |
700mm |
41 |
10m |
CBT-65 |
Single coil |
960mm |
63 |
13m |
CBT-65 |
Single coil |
450mm |
112 |
17m |
BTO-12.15.20.22 |
Cross type |
500mm |
102 |
16m |
BTO-12.15.20.22 |
Cross type |
600mm |
86 |
14m |
BTO-12.15.20.22 |
Cross type |
700mm |
72 |
12m |
BTO-12.15.20.22 |
Cross type |
800mm |
64 |
10m |
BTO-12.15.20.22 |
Cross type |
900mm |
52 |
9m |
BTO-12.15.20.22 |
Cross type |
---------
<1>Intercross barbedmesh
Spiral Intercross thorn mesh ties between two pieces of thorn rope and it is pressed by stainless steel plate and galvanized steel. It shows the shape of intercross not only beautiful but also practical
<2>Single circle barbed mesh
Single circle thorn mesh does not need cramp,it should be installed with the natural form
<3>Beline barbed mesh
Beline barbed mesh has many span species to sellect.it not only saves fees but also constructs quickly when reaching effect.
<4>Fense barbed mesh
Fense barbed mesh is a kind of fencing mesh made by the barbed thorn mesh. The barbed is beautiful and practical.mainly used in fence window military protecting.length and dia can be met according to the requirements of the customer
--------
