36V8AH LiPo4 Battery Pack LiFePo4 For E-bike

1

Model

OSN-PL-3608

2

LxWxH

355x150x45mm             (without controller box)

    3

410x150x45mm               (with controller box)

4

Rated Voltage

38.4V

5

Rated Capacity

8Ah

6

Inner Resistance

<20mΩ

7

Discharge Cut-off Voltage

30V(2.5V any single cell)

8

charge Cut-off Voltage

46.8V (3.9V any single cell)

9

Standard Charge Voltage

43.8V (3.65V any single cell)

10

Standard Charge Current

2A

11

Max charge Current

4A

12

Max discharge Current

15A

13

Charger

CC/CV(Professional Charger)

14

Weight

3.75KG/3.55KG

15

Working Temperature

Charge

0~50°C

   16

Discharge

-20~50°C

17

   Storage Temperature

-20~50°C

18

    Normal Temperature C

≥12Ah

19

       Circle Life

2000 cycles to 80% with 100% DOD under normal temperature
