High Quality Fiber Laser Cutting Machine Factory Price

Name: High Quality Fiber Laser Cutting Machine Factory Price
Brand: Keyi
Availability: InStock

FOB Price

US$ 5,800 - 16,000 / Set

1 Set(Min. Order)

Port Wuhan/Shenzhen/Shanghai
Payment TermsT/T L/C D/P D/A Credit Card PayPal

Request Sample Customized Request Request Free Catalogs

Contact Now

Get lowest price

Product Details

Condition	New	Laser Type	Fiber Laser
CNC or Not	Yes	Cooling Mode	Air Cooling
Control Software	EZCAD	Graphic Format Supported	AI, BMP, DST, DWG, DXF, DXP, LAS, PLT
Working Accuracy	0.01mm	Place of Origin	Hubei, China
Brand Name	Keyi	Model Number	KY-M-FB10/20/50
Power(W)	10W/20W/50W	Certification	CE, Other, CE, FDA
After-sales Service Provided	Engineers available to service machinery overseas

Product Description

High quality fiber laser cutting machine factory price

Product Description

1. Compactness: With the unique all built-in integration design, the optical, electronic and mechanical components are highly integrated, so that the whole machine weighs only 16kg. It can be called the smallest fiber laser marker in the world. In addition, it adopts imported fiber laser, and coupled with all air-cooled design, it need not external cooling devices.

2. High Durability: The laser module has a long service life (greater than 100,000 hours; while the traditional lamp pump YAG can only serve hundreds of hours and the semiconductor can serve 20,000 hours or so).

3. Low consumption: Due to the all air-cooled design, no consumable materials and free of maintenance, it has a low cost at use. Furthermore, it saves energy with a total power of 200W.

4. High speed: It applies imported high-speed galvanometer scanning head, which has greatly reduced the latency and increased the marking speed, which is 3 to 10 times of the first generation of traditional lamp-pumped marker and the second-generation of semiconductor marker (depend on the marking material).

Characteristic

1. Fiber lasers with high photoelectric conversion efficiency

2. Air cooled and low power consumption less than 0.5Kw

3. Good laser beam quality M²<1.2

4. Free maintenance and lifetime can be more than 20000 hours.

5. Compact design and can combine with flying marking or pocket design.

Parameter

Model	KY-FB10/ KY-FB20/ KY-FB50
Marking Range	110mm×110mm (Optional)
Laser Power	10W/20W/30W/50w
Q-frequency	20KHz~80KHz
Laser Wavelength	1064nm
Divergence	0.3mard
Minimum Line Width	0.02mm
Minimum Character	0.15mm
Marking Depth	0 ~0.5mm
Engraving Line Speed	≤7000mm/s
Repeatability Accuracy	±0.001mm
Beam Quality	M2:1.2~1.8
Marking Format	Graphics, Text, Bar Codes, Two-dimensional Code, Automatically Marking the Date, Batch number, Serial number, Frequency, etc.
Graphic Format Supported	AI, BMP, DST, DWG, DXF, DXP,LAS, PLT, JPG, GIF, TGA, PNG, TIF etc.
Working Voltage	220V±10%/50Hz/4A
Unit Power	<0.5kw
Use of the Environment	Clean and Dust Free or Dust less
Working Condition: Humidity	5%-75%,Free of Condensed Water
Laser Module Life	>100000 hours

Sample Show

Our Services

Service Commitment

1, Keyi Optic & Electric provide two years free warranty and life-long maintenance. We provide spare parts and service free during warranty time. After the warranty period shall charge only when maintenance, continue to provide a broad and favorable technical support and spare parts supply.

2, Keyi Optic & Electric will upgrade software free for our products.

3, Keyi Optic & Electric received your repairing call, our after-sales engineers will give a clear answer within one hour, arrived at the scene within 24 hours, to ensure that users do not delay production.
