LiFePO4 Battery 48V2A Charger with Aluminum Case
Specification |
Parameter |
|
No: |
Items |
LiFePO4 Battery 48V2A Charger with Aluminum Case |
1 |
Model: |
OSN-LF4802-A |
2 |
Input Volt: |
100-240V |
3 |
Output Volt: |
58.4V/48V |
4 |
Max. output power |
116.8W |
5 |
Charging current |
2A |
6 |
N.W |
1kg |
7 |
Dimension:(LxWxH) |
148×95×54mm |
8 |
Chargingconnector |
customer requirement |
9 |
Wall plug |
customer requirement |
Detail item information:
1.Charging indicator:
No. |
Item |
Status |
1 |
Power on |
LED1:Red |
2 |
Charging |
LED2: Red |
3 |
Fully charged |
LED2: Green |
2. Input characteristic
No. |
Item |
Technical specification |
Remark |
1 |
Rated input voltage |
220Vac |
Input IEC Europe plugs |
2 |
Input voltage range |
189~264Vac |
|
3 |
AC input voltage frequency |
50~60 Hz |
3.Output characteristic or charge stages:
No. |
Item |
Technical specification |
Remark |
1 |
CC (constant current) |
≤ 58.4Vdc, 2A |
CC=max. current |
2 |
CV (constant voltage) |
58.4 Vdc, 2A↓ |
CV=max. voltage |
3 |
Charging finish |
58.4 Vdc, 0.1A |
5%CC |
4 |
Power efficiency |
≥80% |
Vin=230Vac, rated load |
Feature:
1. Advanced Technology: Machine switching power skill, intelligent charging technology, high power with pulse width modulation technology,
2. High stability: IC of military use, high quality and reliable; with less ripple factor, and less Interference to surrounding equipment.
