NEW!! BMS (Battery Management System) 4S /12.8V 20A Continuous Discharge

NEW!! BMS (Battery Management System) 4S /12.8V 20A Continuous Discharge photo-1
NEW!! BMS (Battery Management System) 4S /12.8V 20A Continuous Discharge photo-2
NEW!! BMS (Battery Management System) 4S /12.8V 20A Continuous Discharge photo-3
NEW!! BMS (Battery Management System) 4S /12.8V 20A Continuous Discharge photo-4
Negotiable MOQ: 100 Pieces (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Guangdong, China
Brand Name:
OSN
Model Number:
PCM-XG L120W80T25 (4S 20-70A)
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Guangdong, China
Brand Name OSN
Model Number PCM-XG L120W80T25 (4S 20-70A)
Composed Type Other
Type Li-Ion
Components Other, Electronic Components
Size L120*W80*T25mm
Voltage 12V
Weight 200g
Nominal Capacity 20A Continuous Discharge Current
Application LiFePO4 Battery Pack, Electric ATV
Product Description

BMS (Battery Management System):

With built-in IC compatible with military standards for over-current, over-discharge, over-charge, short-circuit, adverse-polarity connection, balancing functions

KEY FEATURES:

* Over charge protection
*  Over discharge protection
*  Over current protection
*  Short circuit protection
*  Balancing
*  Low-current lock

Specifications
No.
Test item
Criterion


1


Voltage
Charging voltage
DC:14.4V 3.6V/Cell
Balance voltage for single cell
3.60+0.025V
Balance current for single cell
72+10mA


2


Current
Current consumption for single cell
≤20μA
Max. continuous Charging current
20A
Max. continuous Discharging current
70A


3


Over charge Protection
Over charge detection voltage
3.90+0.025V
Over charge detection delay time
0.5—2S
Over charge release voltage
3.80+0.05V


4


Over discharge protection
Over discharge detection voltage
2.00+0.05V
Over discharge detection delay time
10-300mS
Over discharge release voltage
2.30+0.05V


5


Over current protection
Over current detection voltage
0.62V
Over current detection current
200+20A
Detection delay time
5ms—20mS
Release condition
Cut load, Automatic Recovery


6


Short protection
Detection condition
Exterior short circuit
Detection delay time
200-500us
Release condition
Cut load, Automatic Recovery
7
Resistance
Protection circuitry (MOSFET)
≤20mΩ

8

Temperature
Operating Temperature Range
-40~+85°C
Storage Temperature Range
-40~+125°C
9
Size

L120*W80*T25mm
10
Motor Power

850W or below
