A123 12V 2.3Ah Motorcycle start battery pack- 4S1P | ||
Nominal Capacity: | 2300mAh | |
Nominal Voltage: | 13.2V | |
Element/Cell | A123 26650 cells | |
Configurations: | 4S1P | |
Dimensions (mm): | 106*27*72mm | |
Fully-charged pack voltage: | 14.6V (3.65V per cell) | |
Recommended cut-off voltage: | 10V (2.5V per cell) | |
Minimum voltage: | 8V (2V per cell) | |
Continuous Discharge (C): | 30C | |
Burst Discharge (C): | 60C | |
Maximum Charge Rate (C): | 4.3C | |
Discharge Plug Type: | Anderson Type Connector | |
Power Cord Gauge: | 8 or 10AWG | |
Weight: | 389g | |
Package: | Shrinkable PVC | |
Chemistry: | LiFePO4 Nano-phosphate | |
Applications: | Motorcycle start battery, starter battery | |
Cable Length with red quick disconnector 50A: 8cm 10awg silicone cables out of battery including the connector. | ||
Recommended for:
1) Track/Race bikes up to 600cc
2) Competition Supermotors and Dirtbikes up 450cc.
3) Competition ATVs up to 450cc
4) Daily Driver bikes up to 450cc
Not Recommended for:
1) Street only applications in -600cc bikes (use the 8-cell for street only)
2) Dirt applications where you are on very far rides, (use 8-cell)
3) Cold weather riding below 45 degrees on 500cc or larger
Benefits:
1) Ultra lightweight- Up to 80% less in weight, performance gains in performance vehicles from the loss of weight. Improved handling, braking, and acceleration.
2) Extreme Power- Up to 2.5 times the cranking amps as lead and other forms of lithium. Can turn over large cubic inch V-twin in a much smaller size than lead
3) Ultra Compact- Small size fit in any vehicle easily. Allows more room for Power Commanders, electronics or for hiding batteries on custom builds.
4) No maintenance- No trickle charging needed, can hold a charge up to a year!
5) Better Starting- These batteries offer a substantial increase in Cranking Amps over lead and other lithium...They will offer a faster turn over rate of the motor and larger ignition voltage at start up which can significantly aid in starting the bike.
6) Reliability- These batteries are not affected by vibration as the lead/acid batteries are.
They have the ability to accept up to 1500 charges... almost twice as many as lead/acid
