Computerized quilting machine are sewing equipments for producing all kinds of bedding products.Computerized quilting machine
HFJ-T(series) computerized quilting machines, are sewing equipments for producing all kinds of bedding products. They own novel configuration,adopt hanging structure to make them compact and light. And the capability of them is good and steady. They are ensure to satisfy the desires of designing entirely, become the pick of the basket in congeneric products.
♦ Specifications
Model |
HFJ-26T |
HFJ-28T |
HFJ-30T |
Quilt Size |
2.6m×2.8m |
2.8m×3.2m |
3.0m×3.2m |
Needle Drop Size |
2.4m×2.6m |
2.6m×3.0m |
2.8m×3.0m |
Machine Needle |
SINGER / SCHMETZ MR5 18~21# |
||
Machine Needle |
1000 g/m² |
||
Sewing Speed |
500 ~ 2000 SPM |
||
Stitch Length |
2 ~ 7 mm |
||
Dimensions |
5.4 m×3.5 m×1.4m |
5.6 m×3.7 m×1.4m |
5.6 m×3.9 m×1.4m |
Power |
AC 220V, 50Hz, 1.5Kw |
||
Weight |
1500 Kg |
1600 Kg |
1800 Kg |
♦ Characteristics
O Use industrial control system to keep the machine run reliably, main shaft is driven by inverter, movement of X axis and Y axis by step motor driver.
O Set latest industrial control mainboard, capable of copying pattern and other files from USB-disk, and enable to use USB-disk reboot while other disks in computer can not work.
O Capable of copying pattern and other files from USB-disk and enable to use USB-disk plug and play.
O It’s convenient to copy or delete pattern files by pattern management function.
O With function of pattern viewing and rotating or mirroring pattern, capable of reading patterns of variety forms.
O Capable of counting output, and reboot to zero.
O Both forward and backward modes for retreat quilting, overlap stitch distance can be treated specially, and the stitch length can be changed.
O Trace seeking function makes needle quickly located in its position.
O Display quilting status at any time and prompt operation.
O Two quilting methods: forward and backward, and offer press buttons like forward, backward and needle thread etc.
O Convenient in defining and revising frame range and pattern size with setting and modifying functions.
O Offset function makes it available to join separated patterns accurately.
O Accompanied by change of defining pattern range and space, pattern size scales automatically.
O Supply two sets of pressing-foot device to sewing-head for your option in vary conditions. It’s very easy to change them.
O Single head, single needle, double-line locked style, big rotating shuttle.
O Power waste less than 1Kw.
O Self-detect breaking thread function, needle stays at upper position at pause time and machine stop working while thread breakage automatically.
O Testing system function, can detect the machine working status quickly, it used for repairing machine.
O Main shaft self-detect function effectively avoid the accident of breaking quilt, with protection function against exceeding in limit range.
O Return to original point automatically or manually, it will reduce stops
