4 wire color video door phone with outdoor camera

Specifications

color video door phone with outdoor camera
1)5" TFT LCD
2)Power source:AC/DC adaptor(DC 13.5V/1.2A)
3)factory offer

4 wire color video door phone with outdoor camera

• 008A (outdoor station):
  • Color CCD 1/3-inch night vision camera
  • Doorbell, calling, intercom
  • Works with our all Sipo Indoor monitors
  • Angular field of view lens: Horizontal: 95º, Vertical: 70º, Up level: 12.5º, Down Level: 12.5º
  • Min illumination: O Lux(300mm from Camera)
  • Cable condition: 50m for 0.65mm, 100mm for 0.65mm coaxial cable
  • Wiring: 4-Wire
  • Scanning frequency: H:15.734 KHz/15.625 KHz (for EIA, NTSC), V; 60Hz/50Hz (CCIR, PAL)
  • Operating ambient temperature: -10°C±50°C
  • Dimensions: 99 (W) x 165 (H) x 40 (D)mm
  • Inner package: 200 x 130 x 74mm
  • Carton size: 720 x 310 x 250mm, 20pcs per carton
  • N.W.: 0.7 KGS
  • G.W.: 0.9 KGS

835 (indoor monitor):

• Surface mounting installation
• Calling, intercom
• Watching door entrance
• Pressing button, opening the door
• Plastic case
• Be matched all of our outdoor cameras
• Working voltage: AC 100V - 240V, DC 15V power adapter
• Chime: ding dong chime
• Ambient temperature: - 10 °C + 40°C
• Ambient humidity: 45% - 95%
• Dimensions: 196 (W) x 220 (H) x 52 (D)mm
• Inner package: 240 x 230 x 70mm
• Carton size: 495 x 450 x 290 mm, 10pcs per carton
• N.W.: 1.35 KGS
• G.W.: 1.70KGS
