7inch Color TFT-LCD Display Module

Name: 7inch Color TFT-LCD Display Module
Brand: SIPO
SKU: 118478079

US$ 1 - 20 MOQ: 100 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

SIPO

Model Number:

SIPO-T-70B

Shenzhen Sipo Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

shenzhen

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name SIPO

Model Number SIPO-T-70B

Specifications

Size: 7 inch
Resolution: 480(RGB) x 234
Interface: R.G.B. Vertical Stripe
Display Mode: TM with Normally White

Size: 7 inch
Resolution: 480(RGB) x 234
Interface: R.G.B. Vertical Stripe
Display Mode: TM with Normally White

7inch color TFT-LCD display Module

Feature		Spec
Display Properties	Size	7 inch
	Resolution	800(H)x 3(RGB) x 480
	Interface	R.G.B. Vertical Stripe
	Display Mode	TM with Normally White
	View Range(θT /θB/θL/θR)	Viewing Direction 12 o’clock
	View Range(θT /θB/θL/θR)	60/50/70/70 (degree)
	Aspect Ration	16:9
	Brightness	250cd per square meter
	Contrast	400
Signal input	Signal System	PAL / NTSC
Signal input	Signal amplitude (0.714Vp-pVideo signal,0.286Vp-pSync signal)	0.7~1.4 Vp-p
Power	Operating Voltage	9V - 18 V (Limit24V)
Power	Current	12V(The whole350~370mA)
Start time	Power-up time	<1.5s
Temperature and humidity range	Operating Temperature-(Humidity<80% RH)	-10°C~60°C
Temperature and humidity range	Storage Temperature-(Humidity<80% RH)	-20°C~70°C
Mechanical Characteristics	TFT (W x H x D) (mm)	164.9(W)100(H)5.5(D)
	Active Area-(mm)	154.08 (W)* 85.92 (H)
	Dimensions (W x H x D) (mm)	TBD
	Weight(g)	TBD
