Economic cnc router 1212/cnc wood carving machine/advertising cnc router
1. cnc router standard machine size
about our wood advertising cnc router machine model : SIGN-3030/SIGN-6090/SIGN-1312/SIGN-1318/SIGN-1325
if you want to processing metal ( such as aluminum, cooper, brass ) materials, we suggest you add the water tank
2. Machine Introduction
1).The machine adpot steel structure ,seamless welding,according to the standard industry to produce.
2).X Y and Z adopt Taiwan HIWIN linear square guide rail,high precision ,good dust.
3).X and Y axis adopt rack transmission.faster working,higher efficiency .
4).High performance subdivision stepper motor operates smoothly at maximum speed.
5)..Adopt high quality water cooled spindle,so the machine can keep working for long-time without fault.
6).Has the function of re-carving after break point and power failure.
7).According to the customer's special demand, customize different kinds of cnc router
3. Machine Advantages
1)Top-quality world famous brand components
--best inverter
--TBI ball screw
--HIWIN rail
--leadshine stepper motor and driver
2) Easy and safe operation and low maintenance cost.
-- Free training in our factory
---Less time and less money will be cost on the maintance
3) Humanized and beautiful designing.
---Breakpoint specific memory to keep the carving status when power off, processing time forcast and other functions in case of the accidental power outages.
---Colorful machines’ appearances and high-quality paint make the machine beautiful.
4. Machine Parts :
5. Machine Technical Parameters
Model |
SIGN-1212advertising cnc router |
X,Y Working Area: |
1200*1200mm |
X,Y,Z repositioning Accuracy: |
±0.01mm |
Frame: |
Steel tube structure |
X, Y Structure: |
Rack and Pinion Drive, Hiwin Rail Linear Bearings |
Z Structure: |
Hiwin Rail Linear Bearings and Ball Screw |
Max. Power Consumption: |
(Without spindle) 2.0Kw |
Max. Rapid Travel Rate: |
33000mm/min |
Max. Working Speed: |
25000mm/min |
Spindle Power: |
1.5/2.2kw |
Spindle Speed: |
0-24000RPM |
Drive Motors: |
Stepper (Optional Servo) |
Working Voltage: |
AC380V/50/60Hz,3PH (Option: 220V)) |
Command Language: |
G code |
Operating System: |
Ncstudio (options: DSP /Mach3 PC Software) |
X,Y Resolution |
<0.01mm |
Software Compatibility: |
Type3/UcancameV9 software, (Option: Artcam software) |
Running Environment Temperature: |
0 degree - 45 degree |
Relative Humidity: |
30% - 75% |
Guarantee |
One year |
6. optinal parts
1. rotary system --mainly used for engraving some cylinder materials
2. water tank --mainly used for cooling the material when processing metal material ,avoid the cuter stick the materials
3. dust collector
4. vacuum table and vacuum pump
7. Machine samples
8.Packaging Parts
9.Company Informations
We have a strong professional technical team to provide the best products and have experienced managers with the most perfect price system integration schemes for our customers. We have been established business partner with many customers from Russia, Ukraine, U.S., Japan, South Korea, Canada, Italy, Turkey, Iran, Iraq, Egypt, Brazil, Pakistan etc. more than 50 countries.
We have been experienced in exporting the CNC machine for over 5 years, familiar with the different requirements from all kinds lines. Meanwhile, we insist the principle of “the best products, the most reasonable price, the maximum benefits for customers”, there are prestigious fame in the industry business field
10.After Sale Service
1. Technical support by phone, e-mail or MSN around the clock
2. Friendly English version manual and operation video CD disk
3.7-15 working days after down payment or full payment
4. Machine will be adjusted before it is delivered; operation disk/CD was included.
5. Our technician can give you remote guide online (Skype or MSN) if you have any question
6. Engineers available to service machinery overseas, seller and buyer discuss the charges
11. Contact
