Specifications
Hexagonal chicken mesh wire netting1.hot galvanized and PVC coated
2.Wire dia.:1.0mm-3.2mm
3.flate surface,elegent,practical
BRIFE INTRODUCTION:
Material:
(1)Galvanized zinc coated (2)PVC coated (3)Stainless steel
Process:
(1) reverse twist (2) normal twist
Application:
Hexagonal wire mesh with its good corrosion resistance and oxidation resistance, serves well as strengthening, protection and temperature keeping materials in the form of mesh container, stone cage, isolation wall, boiler cover or poultry fence in construction, chemical, breeding, garden and food processing industries.
Specifications of Galvanized Hexagonal Wire Netting:
Opening Size |
Wire Gauge |
Width Per Roll |
||||
Inch |
mm |
Tolerance |
BWG |
mm |
Feet |
Meter |
3/8" |
10 |
+0.5 |
BWG 27-23 |
0.41-0.64 |
1'-6' |
0.1-2m |
1/2" |
13 |
-1.5 |
BWG 27-22 |
0.41-0.71 |
1'-6' |
0.1-2m |
5/8" |
16 |
+1.0/-2.0 |
BWG 27-22 |
0.41-0.71 |
1'-6' |
0.1-2m |
3/4" |
19 |
+1.0/-2.5 |
BWG 26-20 |
0.46-0.89 |
1'-6' |
0.1-2m |
1" |
25 |
+1.5 |
BWG 25-29 |
0.51-1.07 |
1'-6' |
0.1-2m |
1 1/4'' |
31 |
-3.0 |
BWG 24-18 |
0.56-1.24 |
1'-6' |
0.2-2m |
1 1/2" |
40 |
+2.0/-4.0 |
BWG 23-16 |
0.64-1.65 |
1'-6' |
0.2-2m |
2" |
51 |
+2.0/-4.0 |
BWG 22-14 |
0.71-2.11 |
1'-6' |
0.2-2m |
3" |
76 |
+2.0/-4.0 |
BWG 21-14 |
0.81-2.11 |
1'-6' |
0.3-2m |
4" |
100 |
+2.0/-4.0 |
BWG 20-12 |
0.89-2.80 |
1'-6' |
0.5-2m |
Remarks : The length per roll could be produced according to your need. | ||||||
Other specifications are available, If you have a special requirement, HTM can help. | ||||||
Could be weaved in continuous or reverse twist | ||||||
Specifications of PVC Coated Hexagonal Wire Netting:
Opening |
Wire Gauge |
|
mm |
mm |
|
13mm |
0.9,1.0 |
|
16mm |
0.9,1.0 |
|
19mm |
0.9,1.0 |
|
25mm |
1.0,1.2,1.4 |
|
40mm |
1.0,1.2,1.4,1.6 |
|
50mm |
1.0,1.2,1.4,1.6,2.0 |
|
Remarks: Length:5m,10m,25m,30m Width: 0.5m -2.0m | ||
Other specifications are available according to your order. If you have a special requirement, HTM can help. | ||
Packaging:
