cnc engraving machine cnc router machine 1212
CNC Router features
1. Lathe bed is of high quality by cast steel, after re-treatment, much stronger and more stable.
2. Powerful stepper motor driver, Imported linear guideway, running smoothly, high accuracy,
3. Ball crew round rail transmission, high precision, could engrave 1mm letter clearly.
4. Water cooling spindle (24000rpm), apply to long time processing of wood products.
5. The advanced professional control system compatible with many instruction format,
may achieve process function in interruption of power supply, breakpoint.
6.All the spare parts are provided by most famous brand ,with stable high quality.
Technical Parameters
Model |
SIGN--1212/1312 |
Body material |
Whole cast iron |
Guide way |
XYZ-axis use cylinder guide way |
Driving mode |
XYZ-axis use ball screw |
X,Y-axis working area |
1200*1200mm/1300*1200mm |
Body dimensions(with bracket) |
2100*1800*1450m |
Z-axis working area |
150 or 200 mm |
Max. Feeding height |
120mm or bigger |
Cutting thickness of material |
≤40mm |
Max. travelling speed |
8000mm/min |
Engraving speed |
0-6000mm/min |
Mechanical precision |
0.01mm |
Compatible Software |
Type 3 software , Artcut software , Artcam software |
Max. Power consumption |
3.2KW |
Power source |
AC220/50Hz |
Driving system |
Stepper motor (XYZ-85BYG motor) |
comntrol system |
nc-studio or DSP |
machine parts
machine sample
- Technical support by phone, e-mail or MSN around the clock
- Friendly English version manual and operation video CD disk
- 7-15 working days after down payment or full payment
- .Machine will be adjusted before it is delivered , operation disk/CD was included.
- Our technician can give you remote guide online
- Engineers available to service machinery overseas, seller and buyer diuss the charge
We have been experienced in exporting the CNC machine for over 5 years, familiar with the different requirements from all kinds lines. Meanwhile, we insist the principle of “the best products, the most reasonable price, the maximum benefits for customers”, there are prestigioundustry business field.
customer feedback:
