Help CenterQ235 Hot Sale Scaffolding Pedal Steel Ladder
Related Products
-
Cheap Scaffolding Foot Pedal Plate for ConstructionUS$ 50 - 500MOQ: 25 Sets -
Steel Scaffolding Walking BoardUS$ 15 - 32MOQ: 25 Metric Tons
-
Scaffolding Platform/pedal Painting Platforms/fecade Lift/pole Climber Manufacturer (CE, GOST, ISO Approved)US$ 15 - 32MOQ: 25 Metric Tons
-
Galvanized Scaffolding PlankUS$ 10 - 100MOQ: 25 Metric Tons
-
Steels Scaffolding Plank WalkingUS$ 10 - 100MOQ: 25 Metric Tons
Multidirectional Scaffolding Galvanized Ringlock scaffold system
Ringlock scaffolding uses a simple, unique and bolt-free connection technology.
Sliding the wedge head over the rosette and inserting the wedge into the opening immediately secures the component.
There is still sufficient play to secure the other end of the ledger.
A hammer blow to the wedge transforms the loose connection into a superbly strong structurally rigid one. The face of
the wedge head is now precisely positioned against the standard.
Ringlock Scaffolding Eight A benefits
A Save time during assembly and dismantlingthanks to bolt-free connection technology.
A Safe and simple one-man assembly.
A No loose parts.
A Very little material required.
A Maintenance free and always ready for use.
A Low weight of individual parts.
A Tried and proven range of parts.
A Economic and versatile design that convinces.
Ringlock Scaffolding can be customized by drawings,below is our standard types.
| Product Name | Ringlock Scaffolding System Rosette | ||||
| Brand Name | YS | ||||
| technology | fully automatic circular seam welding | ||||
| Payment | T/T;L/C;and so on | ||||
| Customization | Can be made by drawings | ||||
| Model | Specifications | Texture | Weight/kg | |
| Vertical | YS-LA-250 | Φ60*3.2*250 | Q345B | 2.65 |
| YS-LA-500 | Φ60*3.2*500 | Q345B | 3.75 | |
| YS-LA-1000 | Φ60*3.2*1000 | Q345B | 6.65 | |
| YS-LA-1500 | Φ60*3.2*1500 | Q345B | 9.6 | |
| YS-LA-2000 | Φ60*3.2*2000 | Q345B | 12.5 | |
| YS-LA-2500 | Φ60*3.2*2500 | Q345B | 15.5 | |
| YS-LB-250 | Φ48*3.2*250 | Q345B | 1.89 | |
| YS-LB-500 | Φ48*3.2*500 | Q345B | 2.95 | |
| YS-LB-1000 | Φ48*3.2*1000 | Q345B | 5.3 | |
| YS-LB-1500 | Φ48*3.2*1500 | Q345B | 7.64 | |
| YS-LB-2000 | Φ48*3.2*2000 | Q345B | 9.9 | |
| YS-LB-2500 | Φ48*3.2*2500 | Q345B | 12.3 | |
| Ledger | YS-SG-300 | Φ48*2.5*240 | Q235B | 1.4 |
| YS-SG-600 | Φ48*2.5*540 | Q235B | 2.3 | |
| YS-SG-900 | Φ48*2.5*840 | Q235B | 3.2 | |
| YS-SG-1200 | Φ48*2.5*1140 | Q235B | 4.1 | |
| YS-SG-1500 | Φ48*2.5*1440 | Q235B | 5 | |
| YS-SG-1800 | Φ48*2.5*1740 | Q235B | 5.9 | |
| YS-SG-2100 | Φ48*2.5*2040 | Q235B | 6.8 | |
| YS-SG-2400 | Φ48*2.5*2340 | Q235B | 7.7 | |
| U-head Jeck | YS-T-550 | Φ48*5.0*550 | Q235B | 4.38 |
| Base Jeck | YS-DT-550 | Φ48*5.0*550 | Q235B | 3.53 |
| Vertical Diagonal Brace | YS-XG-600*1500 | Φ33*2.3*1606 | Q195 | 3.92 |
| YS-XG-900*1500 | Φ33*2.3*1710 | Q195 | 4.1 | |
| YS-XG-1200*1500 | Φ33*2.3*1859 | Q195 | 4.4 | |
| YS-XG-1500*1500 | Φ33*2.3*2042 | Q195 | 4.7 | |
| YS-XG-1800*1500 | Φ33*2.3*2618 | Q195 | 5.7 | |
| YS-XG-2100*1500 | Φ33*2.3*2833 | Q195 | 8.22 | |
| Model | Length | Width | Height | |
| Steel Plank With Hook | YS-TB-240*45*900 | 0.9 | 240 | 45 |
| YS-TB-240*45*1200 | 1.2 | 240 | 45 | |
| YS-TB-240*45*1500 | 1.5 | 240 | 45 | |
| YS-TB-240*45*1800 | 1.8 | 240 | 45 | |
| YS-TB-240*45*2100 | 2 | 240 | 45 |
| Steel Stair | Model | Length | Width | Height | Texture | Surface treatment |
| YS-LT-2.1*1.5*0.8 | 2.1 | 1.5 | 0.8 | Q235B | Hot dip galvanizing | |
| YS-LT-2.1*2.0*0.8 | 2.1 | 2 | 0.8 | Q235B | Hot dip galvanizing |
Ringlock Scaffolding Larvish Application
Economic support scaffolding
Scaffolding for formworkers and steelfixers
Façade scaffolding
Birdcage scaffolding
Stairway access
Mobile work scaffolding
Tranches and emergency bridges
Ringlock scaffolding package and transportation
1.bundle with steel strip
2.packaged by waterproof paper
3.packaged by plastic paper
4.bulk in container directly
Other Advantages of ringlock scaffolding
The result of superior design:
Up to 8 connections can be made in the structurally ideal Allround connector on one level and at various angles.
Connections are provided in standard dimensions of 50 cm on all Allround standards. The flat rosette prevents clogging
with dirt ofwhatever type.
Ingenious connection technology:
The four small punchedout openings in the rosette automatically centre the ledger at right angles –the four large openings
allow the angle of alignment to be selected.
Clients mainly care about questions:
| Q1:Are you a trade company or a manufacturer? |
| A:We are the integrated industrial and trade enterprise. We are manufacture for almost 12 years,supply for 5 trading companies,and we established our own trading office in the last 2 years. |
| Q2:Do you have customized service? |
A:Yes,Metal welding customization products are one of our large part hot selling type,Stricted producine by your drawings.We own a whole technical team support of this. |
| Q3:Can you supply samples for our reference? |
| A:Yes,free samples for standard type.Special type may charge a little. |
| Q4:When I want your price,what parameters should I tell you? |
| A:Wall thickness;vertical and ledger length & OD;Base Jack size;and Drawings if customized. |
