3000W Solar Inverter

Name: 3000W Solar Inverter
Brand: SUNPOWER
SKU: 118436845

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Place of Origin:

Taiwan, China

Brand Name:

SUNPOWER

Model Number:

SPXS 1200

EastWest Energy Technology Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Tianjin

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Taiwan, China

Brand Name SUNPOWER

Model Number SPXS 1200

Output Power 1 - 200KW

Output Type Single

Size 430*180*82mm

Weight 9.8 kg

Input Voltage 12/24/48 V

Output Voltage 110VAC ± 5%//220VAC ± 5%

Type DC/AC Inverters

Output Frequency 50Hz ± 3%/60Hz ± 3%

Output Current 2.8A

Specifications

Pure Sine Wave
Solar Inverter 3000W
DC 12V/24V Input, AC 220V output
High efficiency (THD <2 % )
Made in Taiwan

Item	Production Type
	SPXS3000-112	SPXS3000-124		SPXS3000-148		SPXS3000-212		SPXS3000-224	SPXS3000-248
Continuous Output Power	3000W
Maximum output power	3450W
Surge Rating	6000W
Input voltage	12VDC	24VDC	48VDC		12VDC		24VDC			48VDC
Output Voltage	100/110/120VAC±3%				220/230/240VAC±3%
Frequency	50/60HZ±5%
Output Waveform	Pure Sine Wave (THD < 3 %)
Efficiency(full load)	88%	91%	92%		90%		93%			94%
No Load Current Draw	2.8A	1.5A	0.7A		2.8A		1.5A			0.7A
Input Voltage Range	10.5-15	21.0-30	42.0-60		10.5-15		21.0-30			42.0-60
Voltage, Load Indication	LED Red/ Orange/ Green
Fault Indication	LED Red
Automatic Protection	Overload/Short Circuit/Reverse Polarity(Fuse)/ Over or Under Input Voltage Over Temperature
Safety Certification	UL458				EN60950
Electromagnetic Interference	FCC Class B				EN50081-1:1992					e-Mark e13-020866
					EN50082-1:1992
					EN55022B:1994
					EN6 1000-4-2 :1995
					EN6 1000-4-3 :1996
					ENV50204:1995
Operating Temperature Range	-10 °C ~ 50 °C
Store Temperature Range	-30 °C to 70 °C
Cooling	Temperature and Loading Controlled Cooling Fan( Open at 65 °C , Close at 45 °C )
Dimension	452(L)208(W)166(H)mm
Weight	9.8kg
