JA, SH, SDS, SD, SK, SF, E, F, J, M, N, P
QD bushing specifications and sizes
material GG22,GG25, C45
Taper bushing / taper bush/ taper lock Product introduction
Taper bushing is a new type of mechanical coupling components widely used in American and European market, with a high degree of standardization, high precision, compact structure, easy installation and removal, etc.By 8 degrees outside cone and pulley, sprocket and other transmission within the cone compression connection, make all kinds of transmission parts centering precision is greatly increased.Taper sleeve size as the series of standard design.Inside hole keyway according to ISO standards for processing.Interchangeability good commonality, it is suitable for various occasions.
Taper bushing / taper bush/ taper lock advantage
When driving a after a long time running, slot hole and chain may be damaged, if this is the use of the taper sleeve transmission parts, when this happens, simply replace the same specifications used taper sleeve can be restored.Thus greatly improving the service life of the transmission parts, reduce the maintenance cost, to save time.
metric and imperial taper bush
| Description |
| 1. Name: European Standard / Bushing / TB Bushing / Taper Bore - 8065 series |
| ( Bushing , TB Bushing, Taper Bore bushing ) |
| 2. Material: Cast iron, Steel |
| 3. European Type :1008,1108,1210,1610,1615,2012,2517, 3020,3030,3535,4030,4040,5050. |
| 6050, 7060, 8065, 10085, 120100, |
| Features |
| 1. Material: High grade cast iron GG25; Steel C45 |
| 2. Surface treatment: Black-phosphated or original color without finishing |
| 3. Easy on-easy off |
| 4. Machined to high precise tolerance |
| 5. A full range of both metric and imperial sizes taper bushes are available |
| 6. Complete short reach range available, for compact lightweight assemblies |
