Home > Consumer Electronics > Two Way Radio > Handheld Two Way Radio > Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver

Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver

Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver thumbnail-1
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver thumbnail-2
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver thumbnail-3
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver thumbnail-4
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver thumbnail-5
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver thumbnail-6
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver photo-1
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver photo-2
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver photo-3
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver photo-4
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver photo-5
Walkie Talkie Dual Band 128CH Baofeng Uv-5r VOX DTMF Offset Two-Way Radio Transceiver photo-6
US$ 1 - 24 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Fujian, China
Brand Name:
baofeng
Model Number:
Baofeng Uv-5r
Contact Supplier Request Quote Chat Now
Quanzhou XD Wireless Electronics Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
xiamen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Fujian, China
Brand Name baofeng
Model Number Baofeng Uv-5r
Type Handheld
Dimensions 160*43*143mm
Frequency Range 136-174MHz 400-520MHz
Storage Channel 128 Channels
Talk Range 5-10km
Product Description

  Walkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio Transceiver

The BaoFeng UV-5R is a compact hand held transceiver providing 4 watts in the frequency range of 136-174 MHz and 400-480 MHz. It is a compact, economical HT that includes a special VHF receive band from 65 - 108 MHz which includes the regular FM broadcast band. Dual watch and dual reception is supported. You get up to 128 memories. Other features include: selectable wide/narrow, battery save function, VOX, DCS/CTCSS encode, key lock and built in flashlight. Selectable frequency steps include: 2.5, 5, 6.25, 10, 12.5 and 25 kHz. RF power may be selected at 4 or 1 watts. This radio comes with an SMA-Female antenna, flexible antenna, BL-5 Li-ion battery (7.4V 1500 mAh), belt clip, wrist strap, AC adapter (8.4V 600ma) and drop-in charging tray. This radio requires the PC03 FTDI programming cable.



Baofeng Portable Two Way Radio UV-5R

Main Features:

 Output : 5W/1W

  • Frequency Range: 136.00-174.00 MHz /  400.00-520.00MHz
  • Frequency Step Setting
  • High &Low Power Switchover
  • Battery Saving
  • VOX Function
  • Wide/Narrow Band Selection
  • Auto-Back Light
  • Dual Band Standby
  • Time-out Timer (TOT)
  • 50 CTCSS and 104 DCS Codes
  • Voice Prompt
  • ANI Code
  • PC or Manual Program
  • DTMF Code
  • PTT-ID
  • ATUO Keypad Lock
  • Busy Channel Lock Function
  • Dual Band, Dual Display and Dual Standby
  • Emergency Alarm
  • Priory Scanning Function
  • Relay Forwarding Confirmed (1750 HZ)
  • Low Battery Warning
  • U/V Cross Band Dual Watch
  • 25) Dimension: 110x58x32mm

BaoFeng UV-5R

 BAOFENG UV-5R UU Dual Band 136-174/400-520Mhz Radio+Brand New car charger cable

Features:

BAOFENG UV-5R The transceiver is a micro-miniature multiband
FM transceiver with extensive receive frequency coverage,
providing local-area two-way amateur communications along with unmatched monitoring capability

VHF/UHF DUAL-BAND TWO WAY RADIO:

  • Frequency Range: 136-174 / 400-520MHz
  • Dual-Band Display, Dual Freq. Display, Dual-Standby
  • Output Power: 4 /1Watts
  • 128 Channels
  • 50 CTCSS and 104 CDCSS
  • Built-in VOX Function
  • 1750Hz Burst Tone
  • FM Radio (65.0MHz-108.0MHz)
  • LED Flashlight
  • Large LCD Display
  • High /Low RF Power Switchable
  • 25KHz/12.5KHz Switchable
  • Emergency Alert
  • Low Battery Alert
  • Battery Saver
  • Time-out Timer
  • Keypad Lock
  • Monitor Channel
  • Channel Step: 2.5/5/6.25/10/12.5/25KHz
  • ROGER SET
 Dual band, dual display, dual standby A/B band independent operation
 128 groups channels storage  Shortcut menu operation mode
VFO & Memory channels scan  Emergency Alarm
Tri-color background light selectable  0~9 grades VOX selectable
 PTT & ANI ID FM radio
Voice commanding  CTCSS/DCS
   PC programmable
Wide/Narrow Band(25kHz/12.5kHz) Transmitter time-out timer(TOT)
High/Low TX power selectable  Busy channel lock-out(BCLO)



Specifications:

Item number UV-5R
General
Frequency Range 65-108MHz(FM Receive only)
136-174MHZ and 400-520MHZ (TX/RX)
Channel No. 128
Frequency Stability ±2.5ppm
Antenna High gain Dual Band antenna
Antenna Impedance 50Ω
Operating Voltage DC 7.4V
Mode of operation Simple or semi-duplex
Dimension(W x H x D) 100 x 52 x 32 mm
Weight 250g(including battery, antenna)
Transmitter
Output power 4W / 1W (Max 5W)
Modulation Mode 16kΦF3E / 11kΦF3E
Maximum deviation <5kHz(Wide) / <2.5kHz(Narrow)
Spurious Radiation <7μW
Adjacent Ch. power ≤-65dB(Wide) / ≤-60dB(Narrow)
Pre-emphasis characteristics 6dB
Current ≤1.6A(5W)
CTCSS/DCS deviation 0.5±0.1kHz(Wide) / 0.3±0.1kHz(Narrow)
Intermediation sensitivity 8-12mv
Intermediation distortion <10%
Earpiece / mic type : Kenw00d Plug type
Antenna : SMA -Female

Each Set PACKAGE CONTAIN
  • 1 x BAOFENG UV-5R  UU (VHF136-174Mhz UHF 400-520Mhz)
  • 1 x 7.4V 1800mah Li-ion Battery Pack
  • 1 x Dual Band Antenna
  • 1 x Belt Clip
  • 1 x ENG Manual
  • 1 x Desktop Charger ( 100V ~ 240V )+(2pin USA or 3pin UK or 2pin EURO or 2pin Australia)
  • 1 x PTT Earpiece
  • 1 x Brand New car charger cable line






Product Pictures:

Walkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio Transceiver

Walkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio TransceiverWalkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio Transceiver





Packaging & Shipping

Complete set of baofeng uv-5r including belowing items :

'1 x  Baofeng UV-5R walkie talkie

1 x Li-ion Battery
1 x Antenna
1 x Belt Clip
1 x ENG Manual

1 x Headset
1 x Desktop Charger

Walkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio Transceiver

Shipping terms
1-3 business days for sample order
3-5 business days for medium order
5-10 business days for OEM order
Delivery can be Express:DHL,UPS, FedEx, EMS, TNT; shipping logistic etc & post office for samples

Our Services

Our Service

1. OEM & ODM serivice offered

2. Sample's fee can be refund after order reached 1000 sets.

3.Delivery can be Express:DHL,UPS, FedEx, EMS, TNT; shipping logistic etc & post office for samples



Our Warranty

Before delivery , we will check the items' quality strictly one by one . * 12 months for radio body & 6month for accessories warranty, please contact us immediately when you get defective,thanks



Payment terms

Payment(shown on home page to customer anti cheater ): T/T, Western Union,/Paypal payment term (please do NOT believe anybody by Email say Our bank changed, thank you)

Our certificates :

Walkie Talkie Dual band 128CH baofeng uv-5r VOX DTMF Offset Two-Way Radio Transceiver

FAQ



1. Q: What is MOQ(mini Order Quantity)?

A: In general, it is 100pcs. According situation, it is negotiable.



2. Q: do you accept Customized?

A: yes,we did produce as customer requirement for Chile Russian Business Partner,OEM & ODM are welcomed.



3. Q: Could you offer free sample to test?

A: Yes, sure. For regular VIP agency we offer free sample when New Products Launch,for New customer you pay the sample fee first when your Order reach required amount we minus the sample Cost for you.
