Specifications
Low damaged,tem.resistance up to 80 centigradesuperfine fibre
good gas tightness and the bonding strength
Speciality
It is woven specialty by the superfine fibre,in oeder to avoid the harmfulness to the people's health because of the old style fibreglass.
Filter material content static electricity fibre.It filtrate the submicron bug dust(size:1um or is smaller than 1 micron)efficiently;It also have the good performance of the dust catching,large dust holding capacity,high permeability and long working life
In order to increase the intensity of the mesh,every two filter bags are fixed by the metal bar.It will prevent the bags from bursting because of the friction force of the wind,in the high wind speed.The filter bag has six inside linings in order to prevent the filter bag from expanding overly because of the wind pressure,cecause if the filter bags are sheltered from each other,it will reduce the effective filtration area and the filtration efficiency.The edge of the filter bag is made in hot melt way,so it has good gas tightness and the bonding strength,and it does not have the steam leakage or the breakage
The large dust holding capacity,the high efficiency,the low damaged due to pressing
Temp.resistance is up to 80℃
The galvanization frame(the outer edge thickness:20mm and 25mm are all available)
The aluminum alloy frame(the outer edge thickness:20mm and 25mm are all available)
Using
Middle filtration for the air-condition,second-level filtration for the precise dust-free room,pre-filtration for the high efficiency filter
| Avg.efficiency Filter material color Arrestance Using | |||
| 30-35% | white | 92% | Pre-filter for the middle efficiency filter |
| 40-45% | orange | 96% | Commercial building,theater,station,airport |
| 60-65% | green | 97% | Automobile painting room,school,computer room |
| 80-85% | pink | 98% |
Plastic industry,pharmaceutical factory,food products factory. painting factory,electrical factory,hospital,laboratory,dust-free room |
| 90-95% | yellow | 99% |
Precise electronics industry,national defense factory, sterile room,aseptic workshop |
