Foldaway pre-filter mesh pleated filter

Specifications

1.large filtering area;
2.low initial resistance;
3.high air flow'
4.large dust holding capacit

Speciality

Common Applications: dust filtration, pre-filtration in air filter program



Features: large filtering area, low initial resistance, high air flow, large dust holding capacity, completely droppable



Filter Media: Incremental structure of flame-retardant synthetic fiber filter media, conforming to the European DIN53438-F1



Frame: Waterproofing chipboard, abandoned chipboard frame filters can be burned, no pollution, conforming to environmental requirements / metal frame also available. With unique design, it can be reused, reducing cost.



(Specification)



Filter Class	Dimensions W*H*D mm	Rated Airflow m3/h	Average Arrestance	Initial Resistance(pa)	Recommended Final Resistance(pa)	Continuous Temperature(°C)	Frame
G3	595*595*46	3200	85%	35	180	80	Waterproofing chipboard Aluminum alloy Galvanized sheet
	595*495*46	2700
	595*295*46	1600
	495*495*46	2200
G4	595*595*46	3200	90%	45	200	80
	595*495*46	2700
	595*295*46	1600
	495*495*46	2200





Note: Other specifications are available on request
