Direct Factory of Gabion Basket ,gabion,welded Gabion Box

Specifications

PVC Coated/Galvanized Gabion Basket

Gabion Basket  also call gabion basket,gabion box,gabion wall,gabion cage,gabion wall factory,hexagonal mesh gabion box,stone gabion netting,diamond gabion box,hot-dipped galvanized gabion mesh,gabion mesh container,mountain protecting gabion box.

Material:Galvanized iron wire and PVC coated wire,

               Galfan(95%zinc-5%Alu Alloy)low carbon steel wire,which has good ability of resistance corrosion.

Mesh wire: 2.0mm-4.0mm

Mesh size: 6x8m,8x10m,10x12m,12x15m,16x18m

Size:1x1x1m,2x1x1m,3x1x1m,4x1x1m,2x1x0.5m,4x1x0.5m

Selvedge wire diameter: 3.2mm-4.2mm

Lacing/tie wire : 2.2mm/3.2mm

Weave style: Double twist hexagonal mesh

PVC Gabion Basket  Applications:

1.Controlling and leading the river and flood.
2. Flood discharge and lead flow.
3. Rock fall defending.
4. Preventing the water and soil lost.
5. Protecting the bridge.
6. Reinforce fabric.
7. Seashore recovery project.

Galvanized Gabion Basket Advantages:
1. Economic. Just put the stone into the gabion and seal.
2. Easily construct, no special technology needed.
3. Strong capacity of withstand nature destroy, rust-resistance and atrocious weather resistance.
4. Affording Large scale distortion, but never be defeated.
5. The slit between the mesh and stone is good for the growth, which can be the part of the environment around.

6. Excellent Penetrability, which can prevent from the whist by liquid.
7. Saving the transport costs. Which can fold while loading and transport, then assemble.

Gabion Basket Size Specifications

Regular size for gabion box/gabion basket

wire diameter:2.7x3.4x2.2mm,mesh size:80x100mm, 2m*1m*1m Gabion Box

Regular size for gabion mattress/gabion basket

wire diameter:2.2x2.7x2.2mm,mesh size:60x80mm,mattress size:3x2x0.3m

Regular size for gabion mesh roll

wire diameter:2.7x3.4mm,mesh size:60x80mm/80x100mm,roll size:2x50m

Gabion mattress, also called as reno mattress. Gabion mattress is made by double twisted hexagonal mesh of which thickness is much smaller than the length and width. Stones filled in the mattress, mainly used for Water embankment, slope, and other anti-erosion structures, with advantages of flexibility, adaptability. The thickness range of gabion mattress is 0.15-0.3m (including 0.3m) of the structure. It can prevent the river from water flow, storms hit and damage.

Some pictures for you:

If you have any demand,please feel free to contact me!
