Specifications
PA-50 piant stop filter(booth filter,fibreglass filter)Avg.arrenstance(acc.EN779)93%
Air velocity 1.5m/s
Weight:240g
PA-50 piant stop filter(booth filter,fibreglass filter)
Speciality
Made of long fibreglass in non-woven way, large ventilation quantity, small resistance, god efficiency of the dust arrestance for the over-spray
High strength fibreglass increasing tructure; the windward side is green, the leeward side is white
Nonflammability, temperature resistance 170°c
Outer frame may choose the paper frame, the galvanization ion frame, or aluminium alloy frame
Using
Applied to many industry such as pollution controlling, public construction, air-condition, electronic. pharmacy, food and so on.
Spray booth ceiling filters datasheet:
Model |
PA-50/60 |
PA-100 |
Avg.arrestance(acc.EN779) |
92%-96% |
97%-99% |
Initial pressure drop |
15Pa |
20Pa |
Final pressure drop |
250Pa |
280Pa |
Dust holding at tested final |
3200-3600g/m² |
3600-4900g/m² |
Temp.resistance, const |
170°c |
170°c |
Temp, short peaks |
190°c |
190°c |
Normal thickness |
50/60mm |
100mm |
Roll sizes standard |
0.8x20 1.0x20 2.0x20 |
0.8x20 1.0x*20 2.0x20 |
