Specifications
Paint Booth 60mm thickness Fiberglass Filterapplied to painting industries
small resistance &high effiency
variety of siz
Paint Booth 60mm thickness Fiberglass Filter
Specification:
Model |
PA-50/60 |
PA-100 |
Avg.arrestance(acc.EN779) |
92%-96% |
97%-99% |
Initial pessure drop |
15Pa |
20Pa |
Final pessure drop |
250Pa |
280Pa |
Air velocity |
0.7-1.75m/s |
0.7-1.75m/s |
Dust holding at tested final |
3200-3600 g/ |
3600-4900g/ |
Temp.resistance,const |
170 |
170 |
Temp.short peaks |
190 |
190 |
Normal thickness |
50/60mm |
100mm |
MRoll sizes standard |
0.8*20 1.0*20 2.0*20 |
0.8*20 1.0*20 2.0*20 |
Speciality:
1) Made of long fibreglass in non-woven way,large ventilation quantity,small resistance, good efficiency of the dust arrestance for the over-spray.
2 ) It is applied to the superficial spray coating high quality painting-spray filtration, high dust catching, specially , PA-50/60/PA-100 is suitable for using heat recovery system
3 ) High strength fibreglass increasing structure;the windward side is green ,the leeward side is white..
4 ) The low compression performance maintains its outlook,which is completely useful for the filtration fibre to keep the oil mist and the dust
5 ) Nonflammability, heat resistance 170 temperature
6 ) The compression packing may save the fare and the storage space in the transportation.After decompression, it will regain its original condition
7 ) Outer frame may choose the paper frame , the galvanization iron frame,or aluminium alloy frame.
