Specifications
600G exhaust filter media:made of super-long heat-welding and anti-breaking synthetic fiber and addhesive full treatment.Speciality:
1.applied to the air filtration for the painting factory,the spray workshop, stoving varnish room and so on.(especially be used for the automotive factory, the automobile repair shop, the motorcycle factory, the bicycle factory, the operating system of the household applianes painting.
2.made from anti-break organic synthesis fiber in high-powered high melt way
3.Gadual structure,the fibre density increases gradually toward pure air which made the efficiency much higher.
4.prevent the dust in the different densitylevel according to the size of the dust
5.The wind surface of the mash is specially compact,this structure make the filtering matirial keep the high filtering efficiency and large dust holding capacity
6.the types of the material:entire coherency,the surface viscosity,dry processin
7.DIN53438-F1,UL900-class2
SPECIFICATION:
| type | C-600G | C-560G | C-350G | AF-600G | FS-600G | S-600G |
| avg.arrestance | 99% | 98% | 96% | 98% | 98% | 97% |
| initial resistance | 30pa | 35pa | 30pa | 45pa | 35pa | 35pa |
| final resistance | 450pa | 430pa | 400pa | 430pa | 450pa | 450pa |
| dust holding at tested final(g/m2) | 650 | 580 | 380 | 430 | 620 | 680 |
| thickness(mm) | 22 | 22 | 18 | 22 | 22 | 22 |
REMARK:
based on customer's requirements,the whole roll and all the size are supplied .It can be made into the plank filter mesh.
Using
1.Applied to the air filtration for the painting factory, the spray workshop, stoving varnish room and so on.
2.Applied to automotive factory, the auomobile repair shop, the motorcycle fctory, the bicycle factory, the operating system of the household appliances painting.
REMARK:
Based on customer's requirements,the whole roll and all the size are supplied .It can be made into the plank filter mesh.
