Specifications
F5/600G Ceiling filter for auto paint.Material: synthetic fiber with glue
Support: The surface viscosity
Class: F5
AF-600G Ceiling fitler
- It is made from the anti-break organic synthesis fiber in high-powered high melt way;
- The wind surface of the mesh is specially compact, this structure make the filtering material keep the:
- high filteringefficiency
- large dust holding capacity;
- even more;
- Working life;
- Saves the systems operation cost;
3. It is at the customers' choice that the material have the entire coherency, the surface viscosity, dry processin
Using
1.Applied to the air filtration for the painting factory, the spray workshop, stoving varnish room and so on.
2.Applied to automotive factory, the auomobile repair shop, the motorcycle fctory, the bicycle factory, the operating system of the household appliances painting.
Spray booth ceiling filters datasheet:
Type |
C-600G |
C-560G |
C-350G |
AF-600G |
FS-600G |
S-600G |
Material |
Polyester |
|||||
Initial resistance |
30 Pa |
35 Pa |
30 Pa |
45 Pa |
35 Pa |
35 Pa |
Final resistance |
450 Pa |
430 Pa |
400 Pa |
430 Pa |
450 Pa |
450 Pa |
Dust holding at tested final |
650 g/m² |
580 g/m² |
380 g/m² |
430 g/m² |
620 g/m² |
680 g/m² |
Filtration class |
F5 |
|||||
Resistance humidity |
100% |
|||||
Temp.resistance |
120°C |
120°C |
110°C |
120°C |
||
Temp. short peaks |
140°C |
140°C |
120°C |
140°C |
||
Thickness |
22mm |
|||||
Roll Sizes |
1.6*21 2.0*21 1.0*21 |
|||||
