USB wireless barcode reader XL-9310

Function

Parameter

WorkingFrequencyRange

433MHzISM frequency range

Communication Distance

Up to 300m at open places.

Light Source Type

650nm graphic laser diode

Use Mode

Hand-held

Bit error rate

1/5 million

Safety Performance

Meet the Grade II National Criteria for Laser Safety

Barcode Type

EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codaber,Industoal 2 of 5,Interleave 2 of 5,

Matrix 2 of 5, MSI, Chinese postcode etc.

Supported Interface

RS 232, PS2 keyboards, USBetc.

Scanning Mode

Manual

Transmission Rate

RS232 Baudrate: 2400-38400

Resolution (pcs0.9)

0.10mm(4mil)

Depth of Field

10- 350mm (pos0.9)

Reading Speed

100 times/second

Reading angleof elevation

60°

Reading angle of dip

45°

Operating temperature

-20 -45

Storage temperature

-20 -45

Operating humidity

5%-85%

Storage humidity

5%-85%

Power supply

5V

Working current

57mA

Static current

36mA

Fall test

100times/1.5m

Light intensity

Daylight 6000lux max

Electromagnetic interference

Complying with en50081, par1 criteria

External electromagnetic interference resistance

Complying with en50082, par1 criteria

Dustproofing and waterproofing

Complying with icc529 and ip42

Exterior dimension

L x W x H: 95mm x 70mm x 160mm

Materials

ABS+pc

Weight

158g
