1. Fully independent property rights
2. Very comfortable operation sense;
3. Support USB, PS/2, RS232 cable;
4. Service life of button reaches up to 50 million times;
5. Multiple languages (Am. English; French; German).
Light Source |
Visible Laser Diode 650nm |
Scan Pattern |
Single Scan |
Scan Rate |
100 times/second |
Scan Precision |
0.10mm(pcs0.9) |
Scan Width |
30mm |
scan window, 220mm |
200mm |
Scan Depth of field |
0-350mm (0.33mm pos0.9) |
Decode Capability |
EAN-8, EAN-13, UPC-A,UPC-E,Code 39, Code 128, EAN128, Codabar, Industrial 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, etc. |
Tilt |
30 |
Elevation Angle |
65 |
Deflection Angle |
55 |
Support Inferface |
USB or PS/2 or RS232 |
Print Contrast |
30% UPC/EAN 100% |
Mention Pattern |
Buzzer, Indicator |
Scan Mode |
Automatical & Manual scanning |
Size |
L x W x H: 160mm x 70mm x 86mm |
Weight |
126g |
Material |
ABS + PC |
Cable |
Standard 2M straight |
Voltage |
5VDC |
Operating Current |
85mA |
Static Current |
36mA |
Laser Class |
Meet the Grade I National Criteria for Laser Safety |
EMC |
CE & FCC DOC compliance |
Operating Temperature |
0°C to 45°C |
Storage Temperature |
-20°C to 60°C |
Humidity |
5% to 85% relative humidity, non-condensing |
Light Levels |
Daylight, 5000Lux |
Shock |
Designed to withstand 1.5M drops |
