Help CenterScrew High Contact Pressure MU1.5P/V5.0(V5.08) Anti-Drop Fire Prevention Terminal Blocks Cable Connector
Related Products
-
MU2.5P/V7.5 PCB Terminal BlockUS$ 1 - 10MOQ: 10000 Pieces -
2013 New UTL Product MU1.5HB5.0(5.08) Connector PCB Push Terminal Block ConnectorUS$ 0.1 - 10MOQ: 100000 Pieces
-
New Product MU2.5VR7.62 PCB Terminal BlockUS$ 1 - 10MOQ: 10000 Pieces
-
New Product MU1.5/H5.0(5.08) -DG 128-5.0PCB Terminal BlockUS$ 0.1 - 10MOQ: 100000 Pieces
-
New Product MU1.5-H5.08-M1 PCB Terminal BlockUS$ 1 - 10MOQ: 100000 Pieces
Parameter
Voltage |
300V |
Current |
15A |
Wire Size(AWG) |
26-14 |
Cross Section |
1.5 |
Solid(mm2) |
0.2-6 |
Insulation Material |
PA66 |
Inflammability Class(UL94) |
V0 |
Contact |
Brass |
Screw |
M2.5 Steel |
Operation Temperature |
-40°c~+105°c |
Pitch |
5.0(5.08)mm(2-24pole) |
|
Products picture
Brief Introduction
1. Terminals with universal mounting feet which can be installed on the PCB Boards.
2. Closed screw pilot holes to ensure ideal screwdriver operation .
3. For a plurality of cross-sectional level of terminals equipped with a unified attachments,
such as the end plates, packet separator.
4. Potential distribution through a fixed bridge or insert line access terminals central cavity
side plug -in bridge .
5. Terminal: With general-purpose mounting feet, can be installed on computers telephones etc.
6. Closed bolt leading hole will not only facilitate operation of screwd-rivers, also prevent the bolt
from dropping out.
7. Electric potential distribution is realized by eitherconnecting central adaptor to the center of
terminal or inserting a side adaptor to the cone jack.
8. General auxiliaries, such as the end plate, segment spacer, and spacer, are attached for terminal
with multiple sections.
9. The insulating shell is made if imported engineering plastic-polyamide Nylon 66(PA66). It is of
high mechanical intensity, good electic property, and super flexibility.
10. Two ends on the top with white marking system to realize uniformed sign.
11. 15 years lifetime.
12. OEM acceptable.
UTL 25 years experience for all kind of terminal blocks
Products Certificates
Company Introduction
Utility (UTL) Electrical Co., Ltd.
A professional manufacture of all kinds of terminal blocks, which was founded in 1990. Through persistent research and development, we have grown into a leading manufacturer of this field. The main products have gained the certificates, such as VDE, UL, CE, CS, ROHS, ISO9001, CCC and CCS etc.
Factory Details
Company Events
1.) Please kindly inform us which items you are interested & the reasonable price will be provided you upon receipt of your new inquiry ASAP.
2.) Solved the problem with you during using ur products
3.)Free samples will be offered to you for our future cooperation.
YOU can reach me on skype:ivy-utl
TELE: 0086 13758875733
